The VE806 HDMI Over Cat 5 Extender Wall Plate extends HDMI and audio signals up to 60m using Cat 5e cable. It supports popular wide screen formats and ensures excellent video quality over long distance transmissions. The VE806 combination can further extend the distance or multiply sources/displays.
The VE806 can be powered at either the Transmitter or Receiver side, and uses a second Cat 5e cable to transmit the power signal. The VE806’s compact wall plate design does away with bulky cables and allows a neat and convenient installation. It is an ideal solution for function rooms, museums and any environment that requires equipment or cabling to be kept hidden from public view.
Feature :
- Uses two Cat 5e cables to connect the local and remote units – one to transmit video and audio; and another for power *
- Remotely powered from either the Transmitter or Receiver side **
- Extends the distance between HDMI source and HDMI display
- Superior video quality – up to 1080p@60Hz (40m), 1080i@60Hz (60m)
- HDMI (3D, Deep Color); HDCP Compatible
- 8 segment equalization adjustment switch optimizes display quality
- Supports wide screen formats
- Supports hot-plugging
- Decora type design is easily configurable to fit various wall plates
- LED indication of power sources / connection status
- Supports stereo audio
- Built-in 8KV/15KV ESD protection
- Easy installation
- Wall mountable type for a neat and cleaner installation
- Plug-and-play – no software installation required
Note:
*The second Cat 5e cable connection is required to remotely power on either the Transmitter or Receiver.
**A power adapter is provided with this package, and can be used at either the Transmitter or Receiver side, which in turn remotely powers the other unit.
Diagram :
Specification :
| Function | VE806T | VE806R | ||
| Connectors | Video In | 1 x HDMI Type A Female (Black) | N/A | |
| Video Out | N/A | 1 x HDMI Type A Female (Black) | ||
| Audio In | 1 x 3.5mm Stereo Jack (Green) | N/A | ||
| Audio Out | N/A | 1 x 3.5mm Stereo Jack (Green) | ||
| DDC | 1 x RJ-45 Female (Silver) | 1 x RJ-45 Female (Silver) | ||
| Power | 1 x Terminal Block (Green) | 1 x Terminal Block (Green) | ||
| TMDS | 1 x RJ-45 Female (Silver) | 1 x RJ-45 Female (Silver) | ||
| LED | Power | 1 (Green) | ||
| Link | 1 (Amber) | |||
| Switch | EQ Switch | N/A | 1x Knob | |
| Video | 1080p @ 60Hz (40 m), 1080i @ 60Hz (60 m) |
|||
| Power Consumption | DC 9V, 2.9W | |||
| Environment | Operating Temp. | 0–50°C | ||
| Storage Temp. | -20–60°C | |||
| Humidity | 0–80% RH, Non-condensing | |||
| Physical Properties |
Housing | Metal | ||
| Weight | 0.17 kg | 0.17 kg | ||
| Dimensions (L x W x H) |
10.11 x 4.44 x 4.00 cm | 10.11 x 4.44 x 4.00 cm | ||
- The specification and pictures are subject to change without notice.
- All trademarks and logos are the properties of their respective holders.
The VE606 DVI Over Cat 5 Extender Wall Plate extends DVI and audio signals up to 60m using Cat 5e cable. It supports popular wide screen formats and ensures excellent video quality over long distance transmissions. The VE606 combination can further extend the distance or multiply sources/displays.
The VE606 can be powered at either the Transmitter or Receiver side, and uses a second Cat 5e cable to transmit the power signal. The VE606’s compact wall plate design does away with bulky cables and allows a neat and convenient installation. It is an ideal solution for function rooms, museums and any environment that requires equipment or cabling to be kept hidden from public view.
Specification :
The VE156 can be powered at either the Transmitter or Receiver side, and uses a second Cat 5e cable to transmit the power signal. The VE156’s compact wall plate design does away with bulky cables and allows a neat and convenient installation. It is an ideal solution for function rooms, museums and any environment that requires equipment or cabling to be kept hidden from public view.
Spicification :
The VE602 incorporates ATEN’s technology that allows A/V signals to be transmitted over one Cat 5e cable. It uses ATEN default EDID, but is able to learn and save the EDID configuration of the remote display. For dual link video signals, simply use a second Cat 5e cable.
With support for stereo audio and popular widescreen video formats, the VE602 provides crystal-clear image and sound quality for installations where remote DVI video displays are required.
The VE892 accepts an audio-video stream from a local source and serializes the data to pass it over a single 3.125 Gbps optical link (for resolutions up to 1080p@60Hz at 24-bits).
The VE892 can also extend the IR remote control and transfer RS-232 (up to 115kbps) in both directions, allows you to connect serial devices such as touch screens and barcode scanners.
