Multimedia devices flooding today´s market utilize a wide range of formats and resolutions, such that video display compatibility becomes an issue. Most standard display devices can only accommodate one interface at a time. The VC1080 Universal A/V to HDMI Switch with Scaler is a flexible video converter that offers an easy and convenient way of converting multiple analog/digital audio/video input signals into HDMI output. Enjoy a range of video formats, including composite, component, S-video, VGA, and HDMI with one HDMI display.

The VC1080 carries a high-performing scaling engine that converts the video resolution to give you the best image quality. It is equipped with a next generation color engine that automatically adjusts and enhances picture quality. It features a superior 3D de-interlacer function for smooth video playback. The VC1080 uses Smart Video Display technology to match the display’s native resolution, as well as ATEN’s Video DynaSync, which optimizes the video display without any delay when switching devices. The VC1080 also integrates superior video noise reduction and comb filter for maximum viewing comfort.

A built-in bidirectional RS-232 controller makes the VC1080 easy to integrate into control system applications, and configure its settings. With the VC1080 Universal A/V to HDMI Scaler, you can get the most out of your HDMI display making it ideal for boardrooms, classrooms and home theaters.

Feature :

• Converts multiple analog/digital audio/video signals to HDMI output
• Features a built in high-performance scaler function for best image quality
• Integrated next generation color engine – automatic picture quality/color adjustment and enhancement
• Features a superior 3D de-interlacer function for smooth video playback quality (frame buffer 3D motion adaptive video)
• Supports Smart Video Display technology to match the native resolution of the display to optimize video quality
• Video DynaSync™  – Exclusive ATEN technology that eliminates boot-up display problems and optimizes resolution when switching between ports
• Integrated superior video noise reduction
• Supports comb filter – provides superior chrominance and luminance separation function for composite video signal
• Supports HDTV input resolutions: 480i, 480p, 576i, 576p, 720p, 1080i and 1080p; and PC input resolutions: VGA,SVGA, XGA, SXGA, up to UXGA
• Implements ATEN EDID Expert technology allows multi resolution input and display
• Supports optical/coaxial digital audio and one stereo audio output
• RS-232 command control for switching ports and system configuration
• Device selection via front panel pushbuttons, IR remote control, and RS- 232 control signal
• Built-in OSD function for video, audio and system settings configuration
• Supports IR extension using a receiver extension cable
• HDMI and HDCP compatible

Diagram :

Specification :

• The specification and pictures are subject to change without notice.
• All trademarks and logos are the properties of their respective holders.

With more and more HDMI devices entering the Home Theater market, the need for simultaneous access to different HDMI A/V sources is becoming increasingly important. Now, the VS482 4- Port Dual View HDMI Switch offers an easy and affordable way to add HDMI capabilities to your hometheater system by allowing you to switch easily between up to four HDMI A/V sources that are connected to up to two HDMI displays.

The VS482 supports four HDMI video input sources and two HDMI output displays. It is designed for two HDTV or audio/video receiver (AVR) applications. The VS482 complies with HDMI standards, and is designed to support 3D content, as well as Audio Return Channel (ARC) function. The VS482 also offers instant switching and has OSD display controls for video, audio, system configuration and information.

Feature :

• Allows up to four HDMI A/V sources to be connected to two HDMI displays
• HDCP compatible
• HDMI (3D, Audio Return Channel and Deep Color)
• Supports Dolby True HD and DTS HD Master Audio
• Audio Return Channel (ARC) function – connect an HDMI cable to the ARC port to send audio from your source device to your audio/video receiver
• OSD for system configuration setting and information display
• Instant switching between HDMI input sources via front panel pushbuttons or through the RS-232 serial control port
• Feature EDID Expert technology to set up different configurations via different EDID mode
• Allows users to view the HDMI input source port / device for easy selection
• Supports superior video quality – HDTV resolutions of 480p, 720p, 1080i, 1080p (1920×1080); up to WUXGA (1920 x 1200)
• Built-in bi-directional RS-232 serial control port for high-end system control *
• Extra audio from HDMI input signal that supports both optical and coaxial digital audio and one stereo audio output
• IR control signal extension – extend the reach of the IR controller by adding an IR receiver unit
• Rack mountable

  * Note: The VS482 AP and GUI operation instructions can be downloaded from the ATEN website (www.aten.com)

Diagram :

Specification :

• The specification and pictures are subject to change without notice.
• All trademarks and logos are the properties of their respective holders.

The 4-Port HDMI Switch allows you to quickly connect 4 HDMI sources to your HDMI display and easily switch between them via front panel pushbuttons, RS-232 or IR remote control. The front panel’s LEDs indicate the source device selected for the display at a glance.

The VS481B supports Ultra HD 4Kx2K, the newest resolution for high definition displays; Auto Switching modes for auto port selection;Instant Switching for a smooth video transition between HDMI ports with increased efficiency; and features a built-in bi-directional RS-232 serial port that allows the switch to be controlled through a high-end controller, PC, and/or home automation/home theater software package.

Feature :

• Allows up to four HDMI A/V sources to be connected to one HDMI display
• Quick and easy switching between HDMI sources via front panel pushbuttons, RS-232 or IR Remote control
• Supports 340MHz bandwidth for ultrahigh 4kx2k video
• HDMI (3D, Deep Color, 4kx2k); HDCP compatible
• Auto switching modes for auto port selection
• Long distance transmission – up to 15 m (24 AWG)
• Consumer Electronics Control (CEC) support
• Supports Dolby True HD and DTS HD Master Audio
• Built-in bi-directional RS-232 serial remote port for high-end system control
• Instant switching between HDMI input sources
• Supports IR extension using a IR extension cable *
• LED indication of video source devicesNote: The IR extension cable (Part No. 2XRT-0003G) is not included inthis package.
