The VC810 is an HDMI-to-VGA converter that allows you to connect an HDMI source (e.g. laptop, PC, ultrabook, etc) directly to a VGA display (e.g. projector, LCD monitor, etc) without upgrading to an HDMI-compatible display at extra cost. It supports frequently used video resolutions of up to 1920 x 1200. The VC810 is compact and convenient to install with no software needed – simply make the hardware connections. In addition, this plug-nplay converter does not require an external power source, which is ideal for environments like conference room where briefings or presentations take place, ensuring great portability, installation simplicity, and manageability.

Feature :

Diagram :Specification :

• The specification and pictures are subject to change without notice.
• All trademarks and logos are the properties of their respective holders.

The KA7176 KVM Adapter Cable connects the KVM switch to the video, USB and audio ports of the target computer. With its small form factor and light weight design, it represents the next generation of KVM Adapter Cables – offering superior signal compensation and delay skew techniques for greatly enhanced video quality.

Feature :

• Auto Signal Compensation (ASC), no DIP switch setting needed for the different distances
• Keyboard and mouse emulation – keeps your server functioning smoothly when it is disconnected from the switch’s KVM port or relocated to different KVM port
• Lifetime firmware upgrades
• Superior video quality – supports resolution of up to 1600 x 1200 within the distance of up to 50m
• Built in ASIC for greater reliability and compatibility
• CPU module designed with automatic conversion to allow for flexible interface combinations (PS/2, USB) to control all computer types (PC, Mac, Sun)
• Compact size
• Virtual Media Support
• Audio enabled*1680 x 1050 (Reduced blanking) and 1920 x 1200 (Reduced blanking) supported

Diagram :Specification :

• The specification and pictures are subject to change without notice.
• All trademarks and logos are the properties of their respective holders.

The KA7175 USB Virtual Media KVM Adapter Cable connects the KVM switch to the video and USB ports of the target computer. With its small form factor and light weight design, it represents the next generation of USB Virtual Media KVM Adapter Cables – offering superior signal compensation and delay skew techniques for greatly enhanced video quality.

Feature :

• Auto Signal Compensation (ASC), no DIP switch setting needed for the different distances
• Keyboard and mouse emulation – keeps your server functioning smoothly when it is disconnected from the switch’s KVM port or relocated to different KVM port
• Lifetime firmware upgrades
• Superior video quality – supports resolution of up to 1600 x 1200 within the distance of up to 50m
• Built in ASIC for greater reliability and compatibility
• CPU module designed with automatic conversion to allow for flexible interface combinations (PS/2, USB) to control all computer types (PC, Mac, Sun)
• Compact size
• Virtual Media Support

  *1680 x 1050 (Reduced blanking) and 1920 x 1200 (Reduced blanking) supported

Diagram :

Specification :

• The specification and pictures are subject to change without notice.
• All trademarks and logos are the properties of their respective holders.

For smooth operation and added convenience, ATEN´s KA7171 USB-PS/2 KVM Adapter Module is designed to provide a full console connection locally in a KVM over IP Switch or Matrix KVM* installation. The KA7171 allows a PS/2 or USB server to be connected to the switch via Cat 5e/6 cable and provides an extra console via USB keyboard, USB mouse, and monitor to use for extended local operations. In addition, the Privileged Console Control function prevents remote users from operating the device when a local administrator requires full control of the server – reducing conflicts and unwanted operations.

Feature :

• Cat 5e/6 cable connects the device and KVM switch *
• Supports computers with PS/2 or USB keyboards and mice
• Local console operation – control your system from the extended USB keyboard, USB mouse, and monitor via local console
• Pushbutton operating mode selection for privileged console control
• Built-in ASIC for greater reliability and compatibility
• USB overcurrent detection and prevention
• Built-in ESD protection and surge protection
• High resolution video – up to 1920 x 1200@60Hz **
• Supports VGA , SVGA , SXGA , UXGA , WUXGA and multisyncmonitors; local monitor supports DDC; DDC2; DDC2B
• Easy to install – no software required – connecting cables to the devices is all it takes* Compatible products are:
  • KN2116A / KN2132 / KN4116 / KN4132
  • KN2116v / KN2132v / KN4116v / KN4132v
  • KN2124v / KN4124v / KN2140v / KN4140v
  • KM0032, KM0532, KM0932

  ** Depends on KVM switch

Diagram :

Specification :

• The specification and pictures are subject to change without notice.
• All trademarks and logos are the properties of their respective holders.

The Altusen Serial KVM Adapter Cable connected to KVM device allows the control of serial devices through serial ports. This adapter is light and come in compact form factor, ideal for rack-mount or desktop servers.

Feature :

• Hot pluggable – add or remove computers without having to power down the switch
• Support VT100
• Support up to 300m signal transmission
• Lifetime firmware upgrades
• CPU module designed with automatic conversion to allow for flexible interface combinations (PS/2, USB) to control all computer types (Serial)
• Compact size

Diagram :

Specification :

• The specification and pictures are subject to change without notice.
• All trademarks and logos are the properties of their respective holders.
