ATEN VM5808H 8 x 8 HDMI Matrix Switch with Scaler

Posted on January 6, 2015 by

The VM5808H 8 x 8 HDMI Matrix Switch is a distinct HDMI solution that offers an easy and affordable way to route any of 8 HDMI video sources to any of 8 HDMI displays, with a quick view of all port connections via the front panel LCD.

VM5808H-2 The VM5808H includes seamless switching that employs a FPGA matrix architecture that ensures continuous video streams, real-time control and stable signal transmissions. With a built in high-performance scaler, the VM5808H easily converts various input resolutions into various output display resolutions, giving viewers the best video and picture quality across all displays. The switch integrates video wall functionality with an easy to use web GUI that lets you create 16 connection profiles that can be customized into different video wall layouts.

VM5808H-3 The VM5808H is an ideal solution for applications that require multiple HDMI displays with multiple HDMI sources to be conveniently setup in multiple locations, such as for stage presentations, competitions, control centers, and installations that require real-time reports.

Feature :

Connects any of 8 HDMI sources to any of 8 HDMI displays
Long Distance Transmission – supports up to 15 m (24 AWG)
HDMI (3D, Deep color); HDCP 1.4 compatible
Video Wall – provides up to 16 connection profiles that you can customize into layouts using the web GUI
Features a built in high-performance scaler for the best image quality
Easily switch between mulitple sources and multiple displays
Seamless Switch – provides continuous video streams, real-time switching and stable signal transmissions*
Built-in EDID wizard – provides an easy way to customized EDID settings
Configuration and Control via:
• Front panel LCD display and pushbuttons
• IR Remote Control
System Operation:
• Browser Graphical User Interface (GUI)
• Serial controller
• Telnet
Built-in bi-directional RS-232 serial port for high-end system control
Superior video quality – HDTV resolution of 480p, 720p, 1080i and 1080p (1920 x 1080)
Supports Dolby True HD and DTS HD Master audio
Consumer Electronics Control (CEC) support
Power On Detection – If an HDMI source is powered off the VM5808H automatically switches to the next powered-on source
Supports IR signals for remote control
Firmware Upgradeable
Rack Mountable
* If Seamless Switching is enabled, the video output will not display 3D, Deep Color or interlace (i.e., 1080i) resolutions. To make these features available, you must disable Seamless Switching.

Diagram :

Diagram VM5808H Specification :

Connectors	HDMI In	8 x HDMI Type A Female (Black)
	HDMI Out	8 x HDMI Type A Female (Black)
	Ethernet	1 x RJ-45 Female
	RS-232	1 x DB-9 Female (Black)
	IR Input Port	1 x Mini Stereo Jack Female (Black)
	Power	1 x 3-prong AC Socket
	LCD	1 x LCD Module
Switches	In / Out	8 x 8 buttons
	Next	N/A
	Previous	N/A
	Cancel	1 x Pushbutton
	Menu	1 x Pushbutton
	Profile	1 x Pushbutton
	Enter	1 x Pushbutton
	Power	1 x Rocker
LEDs	Menu	1 (Green)
LEDs	Profile	1 (Green)
I/P Rating		100-240Vac; 50-60Hz; 1.0A
Power Consumption		120V/60W; 230V/62W
Environment	Operating Temp.	0 – 50°C
	Storage Temp.	–20 – 60°C
	Humidity	0-80% RH, Non-condensing
Physical Properties	Housing	Metal
	Weight	4.03 kg
	Dimensions ( L x W x H )	43.20 x 26.20 x 4.40 cm

The specification and pictures are subject to change without notice.
All trademarks and logos are the properties of their respective holders.

ATEN VM0808H 8×8 HDMI Matrix Switch

Posted on March 12, 2014 by

The ATEN VanCryst™ VM0808H 8×8 HDMI Matrix Switch is a distinct HDMI solution that offers an easy and affordable way to route any of 8 HDMI video sources to any of 8 HDMI displays,and view them in any arrangement.

As a matrix switch the VM0808H allows eight HDMI source devices to cross connect to eight HDMI displays at the same time, while independently controlling the output in any array possible, giving you the ultimate flexibility and control in any multi-display HDMI installation.

Feature :

Connects any of 8 HDMI sources to any of 8 HDMI displays
Long Distance Transmission – supports up to 20 meters (24 AWG)
HDMI (3D, Deep Color) and HDCP compatible
Consumer Electronics Control (CEC) allows interconnected HDMI devices to communicate and respond to one remote control
Easily switch between multiple sources and multiple displays
Local Operation:
• Front panel LCD display
• Tuner Dials and Pushbuttons
• IR Remote Control
• Serial controller
Remote Operation:
• Browser Graphical User Interface (GUI)
Superior video quality – HDTV resolution of 480p, 720p, 1080i, and 1080p (1920 x 1080), VGA, SVGA, SXGA, UXGA and WUXGA (1920 x 1200)
Supports Dolby True HD and DTS HD Master audio
Signaling rates up to 2.25 Gbits in support of 1080p display
Feature EDID Expert technology to set up different confi gurations via different EDID modes
Power on Detection – If an HDMI sources is powered off, the VM0808H can automatically switch to the next powered-on source
Firmware upgradeable
Rack Mountable
* Note: The VM0808H AP and GUI operation instructions can be downloaded from the ATEN website (www.aten.com)

Diagram :

Specification :

Connectors	HDMI In	8 x HDMI Type A Female (Black)
	HDMI Out	8 x HDMI Type A Female (Black)
	Ethernet	1 x RJ-45 Female
	RS-232	1 x DB-9 Female (Black)
	IR Input Port	1 x Mini Stereo Jack Female (Black)
	Power	1 x 3-prong AC Socket
Switches	In	1 x Tuner Button
	Out	1 x Tuner Button
	Esc	1 x Pushbutton
	Menu	1 x Pushbutton
	Profile	1 x Pushbutton
	Enter	1 x Pushbutton
	Power	1 x Rocker
LEDs	Menu	1 (Green)
LEDs	Profile	1 (Green)
I/P Rating		100-240VAC ; 50-60Hz;1A
Power Consumption		120V/32W ; 230V/34W
Environment	Operating Temp.	0 – 50°C
	Storage Temp.	–20 – 60°C
	Humidity	0-80% RH, Non-condensing
Physical Properties	Housing	Metal
	Weight	4.01 kg
	Dimensions ( L x W x H )	43.24 x 27.12 x 4.40 cm

The specification and pictures are subject to change without notice.
All trademarks and logos are the properties of their respective holders.

ATEN VM0404H HDMI Matrix Switch

Posted on March 10, 2014 by

The VM0404H is a 4×4 HDMI Matrix Switch that provides a convenient way to route high definition video and audio from any of four HDMI sources to any of four HDMI displays. The VM0404H allows you to connect four HDMI devices (such as an HD camcorder or satellite box, HD-DVD player, hi-def Blu-ray player, home theater PC, stand-alone streaming media player, or gaming console) to four HDMI monitors, displays, projectors or TVs at the same time.

The remote control and convenient front panel pushbuttons allow you to quickly and easily cycle through HDMI sources and displays, while the front panel LEDs indicate the source device for each display at a glance.

Feature :

Connects any of four HDMI sources to any of four HDMI displays
Toggle between HDMI sources and displays using remote control or front panel pushbuttons
Superior video quality – HDTV resolutions of 480p, 720p,1080i, 1080p (1920×1080); VGA, SVGA, SXGA, UXGA (1600×1200), and WUXGA (1920 x 1200)
HDCP 1.1 compatible
Consumer Electronics Control (CEC) allows interconnected HDMI devices to communicate and respond to one remote control
HDMI (3D, Deep Color)
Supports Dolby True HD and DTS HD Master Audio
Up to 60 Hz refresh rate
Long-distance transmission – up to 20 m (24 AWG)
Built-in bi-directional RS-232 serial remote port for high-end system control *
Power On Detection – if one HDMI source is powered off, the VM0404H will automatically switch to the next powered-on source
DDC compatible
Signaling rates up to 2.25 Gbits in support of 1080p display
All-metal casing
Easy and affordable way to add four HDMI inputs to your multiscreen home theater system
Rack Mountable* Note: The VM0404H AP and GUI operation instructions can be downloaded from the ATEN website (www.aten.com)

Diagram :

Specification :

Display Connections	Direct		4
HDMI Input Connections			4
Connectors	Device	HDMI In	4 x HDMI Type A Female (Black)
	Display	HDMI Out	4 x HDMI Type A Female (Black)
	RS-232 Port		1 x DB-9 Female (Black)
	Power		1 x DC Jack
Switches	Port Selection		4 x Pushbuttons
LEDs	Selected		16 (Green)
Video Resolution			HDTV resolutions up to 1080p; computer resolutions up to WUXGA (1920×1200)
Power Consumption			DC5.3V, 9W
Environment	Operating Temp.		0-50°C
	Storage Temp.		-20-60°C
	Humidity		0-80% RH, Non-condensing
Physical Properties	Housing		Metal
	Weight		1.86 kg
	Dimensions ( L x W x H )		43.20 x 15.40 x 4.40 cm

The specification and pictures are subject to change without notice.
All trademarks and logos are the properties of their respective holders.

ATEN VM1616T Media Matrix Solution 16×16 Cat 5 A/V Matrix Switch

Posted on March 3, 2014 by

The VanCryst™ Media Matrix Solution is a combination of the VM1616T 16×16 Cat 5 A/V Matrix Switch and the VE500/VE300 A/V Over Cat 5 Extender. The VM1616T is a Matrix Switch that routes and distributes audio, video, and RS-232 signals over distances of up to 300 m with 1920 x 1200 video resolution. The VM1616T can receive data from up to 16 audio/video sources and transmit data to up to 16+1 audio/video displays. The VM1616T offers several convenient ways to access and control the source devices: locally, with front panel pushbuttons and an RS-232/RS-485/RS-422 serial port; and remotely, over the Internet with a browser-based web page interface.

The Media Matrix Solution is an ideal solution when long runs to the A/V output locations are required, and where versatility and security are essential. The VM1616T is designed for deployment in environments that involve routing video signals such as those found in casinos, transportation and logistics centers, traffic control centers, port security facilities, industrial supervision settings, etc. Feature :

Connects any of 16 Cat 5 A/V inputs to any of 16 Cat 5 A/V outputs in combination with ATEN VE500/VE300 A/V Over Cat 5 Extender system
Long signal range – supports up to 300 meters between VE500T/VE300T transmitters and VE500R/VE500RQ, VE300R/VE300RQ receivers
Easily switch between multiple sources and multiple displays
Local Operation: • Front panel LCD display and pushbuttons • Serial controller
Remote Operation: • Browser Graphical User Interface (GUI) • Telnet
Supports additional local display – provides an extra output source
Built-in bi-directional RS-232 serial port for high-end system control
Supports video quality – up to 1920 x 1200@60Hz; DDC2B
Supports stereo and balanced audio
Automatic and adjustable video quality
Independent switching of audio and video sources – any audio source can be connected to any video source for output flexibility
Upgradeable firmware
Rack Mountable* Note: The VM1616T AP and GUI operation instructions can be downloaded from the ATEN website (www.aten.com)

Diagram :Specification :

Input Connections	Direct			0
	Max.			16 x Transmitter
Display Connections	Direct			1
	Max.			17 (1 x Local; 16 x Receiver)
Connectors	Local	Audio Out	Balanced	1 x Captive Screw Connector, 5 pole
			Stereo	1 x Mini Stereo Jack Female (Green)
		Video Out		1 x HDB-15 Female (Blue)
	Unit to Unit	A/V In		16 x RJ-45 Female
		A/V Out		16 x RJ-45 Female
	Ethernet			1 x RJ-45 Female
	Serial	RS-232		1 x DB-9 Female (Black); 1 x DB-9 Male (Black)
		RS-485 / RS-422		1 x Captive Screw Connector, 5 pole
	LCD			1 x LCD module
	Power			1 x 3-prong AC Socket
Switches	In / Out			2 x Dial / Pushbutton
	Menu			1 x Pushbutton
	Profile			1 x Pushbutton
	Esc			1 x Pushbutton
	Enter			1 x Pushbutton
	Power			1 x Rocker
LEDs	Menu			1 (Green)
	Profile			1 (Green)
I/P Rating				100-240V~; 50-60Hz; 1.0A
Power Consumption				120V / 34W; 230V / 35W
Environment	Operating Temp.			0-50°C
	Storage Temp.			-20-60°C
	Humidity			0-80% RH, Non-condensing
Physical Properties	Housing			Metal
	Weight			3.63 kg
	Dimensions ( L x W x H )			43.24 x 27.12 x 4.40 cm

The specification and pictures are subject to change without notice.
All trademarks and logos are the properties of their respective holders.

ATEN VM0808T Media Matrix Solution 8×8 Cat 5 A/V Matrix Switch

Posted on February 27, 2014 by

The VanCryst™ Media Matrix Solution is a combination of the VM0808T 8×8 Cat 5 A/V Matrix Switch and the VE500 / VE300 A/V Over Cat 5 Extender. The VM0808T is a Matrix Switch that routes and distributes audio, video, and RS-232 signals over distances of up to 300 m with 1280×1024 video resolution.

The VM0808T can receive data from up to 8+1 audio/video sources and transmit data to up to 8+1 audio/video displays. The VM0808T offers several convenient ways to access and control the source devices: locally, with front panel pushbuttons and an RS-232/ RS-485/RS-422 serial port; and remotely, over the Internet with a browser-based web page interface.

The Media Matrix Solution is an ideal solution when long runs to the A/V output locations are required, and where versatility and security are essential. The VM0808T is designed for deployment in environments that involve routing video signals such as those found in casinos, transportation and logistics centers, traffic control centers, port security facilities, industrial supervision settings, etc.

Feature :

Connects any of 8 Cat 5 A/V inputs to any of 8 Cat 5 A/V outputs in combination with ATEN VE500/VE300 A/V Over Cat 5 Extender system
Long signal range – supports up to 300 meters between VE500T/VE300T transmitters and VE500R/VE500RQ/ VE300R/VE300RQ receivers
Easily switch between multiple sources and multiple displays
Local Operation:
• Front panel LCD display and pushbuttons
• Serial controller
Remote Operation:
• Browser Graphical User Interface (GUI)
• Telnet
Supports additional local input and local display – provides an extra input / output source
Built-in bi-directional RS-232 serial port for high-end system control
Supports Video Quality – up to 1920 x 1200@60Hz; DDC2B
Supports stereo and balanced audio
Automatic and adjustable video and audio quality
Independent switching of audio and video sources – any audio source can be connected to any video source for output flexibility
Firmware upgradeable
Rack Mountable
* Note: The VM0808T AP and GUI operation instructions can be downloaded from the ATEN website (www.aten.com)

Diagram :

Specification :

Input Connections	Direct			1 (Local)
	Max.			9 (1 x local input; 8 x VE500T Transmitter)
Display Connections	Direct			1 (Local)
	Max.			9 (1 x local display; 8 x VE500R/RQ Receiver)
Connectors	Local	Audio In	Balanced	1 x Captive Screw Connector, 5 pole
			Stereo	1 x Mini Stereo Jack Female (Green)
		Video In		1 x HDB-15 Male (Blue)
		Audio Out	Balanced	1 x Captive Screw Connector, 5 pole
			Stereo	1 x Mini Stereo Jack Female (Green)
		Video Out		1 x HDB-15 Female (Blue)
	Unit to Unit	A/V In		8 x RJ-45 Female
		A/V Out		8 x RJ-45 Female
	Ethernet			1 x RJ-45 Female
	Serial	RS-232		1 x DB-9 Female (Black); 1 x DB-9 Male (Black)
		RS-485 / RS-422		1 x Captive Screw Connector, 5 pole
	Power			1 x 3-prong AC Socket
Switches	Up / Down / Left / Right			4 x Pushbutton
	Menu			1 x Pushbutton
	Audio			1 x Pushbutton
	Esc			1 x Pushbutton
	Enter			1 x Pushbutton
	Power			1 x Rocker
Display				1 x LCD Display (Green)
LEDs	Menu			1 (Blue)
	Audio			1 (Blue)
	Up / Down / Left / Right			4 (Blue)
Power Consumption				110V / 16W; 220V / 17W
Environment	Operating Temp.			0-50°C
	Storage Temp.			-20-60°C
	Humidity			0-80% RH, Non-condensing
Physical Properties	Housing			Metal
	Weight			3.50 kg
	Dimensions ( L x W x H )			43.20 x 25.30 x 4.40 cm

The specification and pictures are subject to change without notice.
All trademarks and logos are the properties of their respective holders.
