Industrial 10-port desktop managed Ethernet switch with 8×10/100Base-T(X) and 2×100/1000Base-X, SFP socket, power supply included DES-3082GP-P

Overview

DES-3082GP-P is desktop managed Redundant Ring Ethernet switch with 8×10/100Base-T(X) and 2×100/1000Base-X SFP ports. With completely support of Ethernet Redundancy protocol, O-Ring (recovery time < 10ms over 250 units of connection), Open-Ring, O-Chain and MSTP/RSTP:2004/STP (IEEE802.1s/w/D) can protect your mission-critical applications from network interruptions or temporary malfunctions with its fast recovery technology. Another Open-Ring technology is also supported which can applied for other vendor’s proprietary ring. O-Chain is the revolutionary network redundancy technology that provides the add-on network redundancy topology for any backbone network, O-Chain allows multiple redundant network rings of different redundancy protocols to join and function together as a larger and more robust compound network topology. O-Chain providing ease-of-use while maximizing faultrecovery swiftness, flexibility, compatibility, and cost-effectiveness in one set of network redundancy topology. All function of DES-3082GP-P can be managed centralized and convenient by a powerful windows utility — Open-Vision. In addition, the wide operating temperature range from -40 to 70°C can satisfy most of operating environment. Therefore, the switch is one of the most reliable choices for highly-managed Fiber Ethernet application.

Features

• • World’s fastest Redundant Ethernet Ring: O-Ring (recovery time < 10ms over 250 units of connection)
  • Open-Ring support the other vendor’s ring technology in open architecture
  • O-Chain allow multiple redundant network rings
  • Support standard IEC 62439-2 MRP (Media Redundancy Protocol) function
  • STP/RSTP:2004/MSTP supported
  • Support PTP Client (Precision Time Protocol) clock synchronization
  • Support IPV6 new internet protocol version
  • Provided HTTPS/SSH protocol to enhance network security
  • Support TACACS+ and 802.1x User Authentication for security

Specification

Specifications ORing Switch Model DES-3082GP-P Physical Ports 10/100 Base-T(X) Port in RJ45 Auto MDI/MDIX 8 100/1000Base-X SFP Port 2 Technology Ethernet Standards IEEE 802.3 for 10Base-T IEEE 802.3u for 100Base-TX IEEE 802.3z for 1000Base-X IEEE 802.3ab for 1000Base-T IEEE 802.3x for Flow control IEEE 802.3ad for LACP (Link Aggregation Control Protocol ) IEEE 802.1p for COS (Class of Service) IEEE 802.1Q for VLAN Tagging IEEE 802.1D for STP (Spanning Tree Protocol) IEEE 802.1D-2004 for RSTP:2004 (Rapid Spanning Tree Protocol 2004) IEEE 802.1w for RSTP (Rapid Spanning Tree Protocol) IEEE 802.1s for MSTP (Multiple Spanning Tree Protocol) IEEE 802.1x for Authentication IEEE 802.1AB for LLDP (Link Layer Discovery Protocol) MAC Table 8192 MAC addresses Priority Queues 4 Processing Store-and-Forward Switch Properties Switching latency: 7 us Switching bandwidth: 5.6Gbps Max. Number of Available VLANs: 4096 IGMP multicast groups: 1024 Port rate limiting: User Define Security Features Enable/disable ports, MAC based port security Port based network access control (802.1x) VLAN (802.1Q ) to segregate and secure network traffic Supports Q-in-Q VLAN for performance & security to expand the VLAN space Radius centralized password management SNMP v1/v2c/v3 encrypted authentication and access security Https / SSH enhance network security Software Features STP/RSTP:2004/MSTP (IEEE 802.1D/w/s) Redundant Ring (O-Ring) with recovery time less than 10ms over 250 units Modbus/TCP supported QoS supported TOS/Diffserv supported Quality of Service (802.1p) for real-time traffic VLAN (802.1Q) with VLAN tagging and GVRP supported IGMP Snooping for multicast filtering Port configuration, status, statistics, monitoring, security SNTP for synchronizing of clocks over network Support PTP Client (Precision Time Protocol) clock synchronization DHCP Server / Client support Port Trunk support MVR (Multicast VLAN Registration) support Modbus TCP Network Redundancy O-Ring Open-Ring O-Chain MRP STP/RSTP:2004/MSTP Warning / Monitoring System Relay output for fault event alarming Syslog server / client to record and view events Include SMTP for event warning notification via email Event selection support RS-232 Serial Console Port RS-232 in DB9 connector with console cable. 9600bps, 8, N, 1 LED Indicators Power Indicator Green : Power LED x 1 Status Indicator (Status) Green : Power LED x 1 R.M. Indicator (R.M) Green : Indicate system operated in O-Ring master mode O-Ring Indicator (Ring) Green : Indicate system operated in O-Ring mode Fault Indicator (Fault) Green for port Link/Act. Amber for Duplex/Collision 10/100Base-T(X) RJ45 Port Indicator Green for port Link/Act. Amber for Duplex/Collision 100/1000Base-X SFP Port Indicator Green for port Link/Act. Fault Contact Relay Relay output to carry capacity of 1A at 24VDC Power Redundant Input Power One 100~240VAC with power cord Power Consumption (Typ.) 9 Watts Overload Current Protection Present Physical Characteristics Enclosure IP-30 Dimensions (W x D x H) 200 (W) x 130 (D) x 88(H) mm (7.87 x 5.12 x 3.46 inch) Weight (g) 1385 g Environmental Storage Temperature -40 to 85°C (-40 to 185°F) Operating Temperature -40 to 70°C (-40 to 158°F) Operating Humidity 5% to 95% Non-condensing Regulatory Approvals EMI FCC Part 15, CISPR (EN55022) class A EMS IEC61000-4-2 (ESD), IEC61000-4-3 (RS), IEC61000-4-4 (EFT), IEC61000-4-5 (Surge), IEC61000-4-6 (CS), IEC61000-4-8, IEC61000-4-11 Shock IEC60068-2-27 Free Fall IEC60068-2-32 Vibration IEC60068-2-6 Safety EN60950-1 Warranty 5 years

Industrial 8-port Unmanaged Ethernet Switch

Overview

IES-1080/1062 series are unmanaged Ethernet switches with 6×10/100Base-T(X) and 2x100Base-FX, 10/100/1000Base-T(X), 1000Base-SX or 1000Base- LX ports. IES-1080/1062 series support redundant power input, relay output alarm, and surge protection. The wide operating temperature range from -40°C to 70°C can satisfy most of operating environments.

Features

• • IES-1080 provide 8×10/100Base-T(X) ports
  • IES-1062GT provide 6×10/100Base-T(X) and 2×10/100/1000Base-T(X) ports
  • IES-1062FX series provide 6×10/100Base-T(X) and 2x100Base-FX fiber ports
  • IES-1062GF series provide 6×10/100Base-T(X) and 2x1000Base-X fiber ports
  • Triple redundant DC power inputs of terminal block and power jack
  • Support auto-negotiation and auto-MDI/MDI-X
  • Support store and forw ard transmission
  • Support flow control
  • Warning system by relay output
  • Rigid IP-30 housing design
  • DIN-Rail and wall mounting enabled

Specification

Specifications ORing Switch Model IES -1062GF-MM-SC IES -1062GF-SS-SC Physical Ports 10/100Base-T(X) Ports in RJ45 Auto MDI/MDIX 6 6 Fiber Ports Number 2 2 Fiber Ports Standard 1000Base-SX 1000Base-LX Fiber Mode Multi-mode Single-mode Fiber Diameter (μm) 62.5/125 μm 50/125 μm 9/125 μm Fiber Optical Connector SC SC Fiber Ports Specifications Typical Distance (km) 0.55 km 10 km Wavelength (nm) 850 nm 1310 nm Max. Output Optical Power (dBm) -4 dBm -3 dBm Min. Output Optical Power (dBm) -9.5 dBm -9.5 dBm Max. Input Optical Power(Saturation) 0 dBm -3 dBm Min. Input Optical Power (Sensitivity) -18 dBm -20 dBm Link Budget (dB) 8.5 dB 10.5 dB Technology Ethernet Standards IEEE 802.3 for 10Base-T IEEE 802.3u for 100Base-TX and 100Base-FX IEEE 802.3ab for 1000Base-T IEEE 802.3z for 1000Base-X IEEE 802.3x for Flow control MAC Table 8192  MAC addresses Processing Store-and-Forward LED Indicators Power Indicator Green : Power LED x 3 Fault Indicator Amber : Indicates PWR1 or PWR2 failure occurred 10/100Base-FX RJ45 Port Indicator Green for port Link/Act. Amber for Duplex/Collision 10/100/1000Base-T(X) / Fiber Port Indicator Green for port Link/Act. Amber for Link Fault contact Relay Relay output to carry capacity of 1A at 24VDC Power Redundant Input Power Triple DC inputs. 12~48VDC on 7-pin terminal block, 12~45VDC on power jack Power Consumption (Typ.) 6 watts 6 watts Overload Current Protection Present Reverse Polarity Protection Present on terminal block Physical Characteristics Enclosure IP-30 Dimensions (W x D x H) 52(W) x 106.1(D) x 144.3(H) mm (2.05×4.18×5.68 inch.) Weight (g) 685 g 685 g Environmental Storage Temperature -40 to 85°C (-40 to 185°F) Operating Temperature -40 to 70°C (-40 to 158°F) Operating Humidity 5% to 95% Non-condensing Regulatory Approvals EMI FCC Part 15, CISPR (EN55022) class A, EMS IEC61000-4-2 (ESD), IEC61000-4-3 (RS), IEC61000-4-4 (EFT), IEC61000-4-5 (Surge), IEC61000-4-6 (CS), IEC61000-4-8, IEC61000-4-11 Shock IEC60068-2-27 Free Fall IEC60068-2-32 Vibration IEC60068-2-6 Safety EN60950-1, UL508(E331061) MTBF (Hours) (MIL-HDBK-217F2, GB, GC, 25°C ) 370,965 370,965 Warranty 5 years

Industrial 8-port Unmanaged Ethernet Switch

Overview

IES-1080/1062 series are unmanaged Ethernet switches with 6×10/100Base-T(X) and 2x100Base-FX, 10/100/1000Base-T(X), 1000Base-SX or 1000Base- LX ports. IES-1080/1062 series support redundant power input, relay output alarm, and surge protection. The wide operating temperature range from -40°C to 70°C can satisfy most of operating environments.

Features

• • IES-1080 provide 8×10/100Base-T(X) ports
  • IES-1062GT provide 6×10/100Base-T(X) and 2×10/100/1000Base-T(X) ports
  • IES-1062FX series provide 6×10/100Base-T(X) and 2x100Base-FX fiber ports
  • IES-1062GF series provide 6×10/100Base-T(X) and 2x1000Base-X fiber ports
  • Triple redundant DC power inputs of terminal block and power jack
  • Support auto-negotiation and auto-MDI/MDI-X
  • Support store and forw ard transmission
  • Support flow control
  • Warning system by relay output
  • Rigid IP-30 housing design
  • DIN-Rail and wall mounting enabled

Specification

Specifications ORing Switch Model IES -1062GF-MM-SC IES -1062GF-SS-SC Physical Ports 10/100Base-T(X) Ports in RJ45 Auto MDI/MDIX 6 6 Fiber Ports Number 2 2 Fiber Ports Standard 1000Base-SX 1000Base-LX Fiber Mode Multi-mode Single-mode Fiber Diameter (μm) 62.5/125 μm 50/125 μm 9/125 μm Fiber Optical Connector SC SC Fiber Ports Specifications Typical Distance (km) 0.55 km 10 km Wavelength (nm) 850 nm 1310 nm Max. Output Optical Power (dBm) -4 dBm -3 dBm Min. Output Optical Power (dBm) -9.5 dBm -9.5 dBm Max. Input Optical Power(Saturation) 0 dBm -3 dBm Min. Input Optical Power (Sensitivity) -18 dBm -20 dBm Link Budget (dB) 8.5 dB 10.5 dB Technology Ethernet Standards IEEE 802.3 for 10Base-T IEEE 802.3u for 100Base-TX and 100Base-FX IEEE 802.3ab for 1000Base-T IEEE 802.3z for 1000Base-X IEEE 802.3x for Flow control MAC Table 8192  MAC addresses Processing Store-and-Forward LED Indicators Power Indicator Green : Power LED x 3 Fault Indicator Amber : Indicates PWR1 or PWR2 failure occurred 10/100Base-FX RJ45 Port Indicator Green for port Link/Act. Amber for Duplex/Collision 10/100/1000Base-T(X) / Fiber Port Indicator Green for port Link/Act. Amber for Link Fault contact Relay Relay output to carry capacity of 1A at 24VDC Power Redundant Input Power Triple DC inputs. 12~48VDC on 7-pin terminal block, 12~45VDC on power jack Power Consumption (Typ.) 6 watts 6 watts Overload Current Protection Present Reverse Polarity Protection Present on terminal block Physical Characteristics Enclosure IP-30 Dimensions (W x D x H) 52(W) x 106.1(D) x 144.3(H) mm (2.05×4.18×5.68 inch.) Weight (g) 685 g 685 g Environmental Storage Temperature -40 to 85°C (-40 to 185°F) Operating Temperature -40 to 70°C (-40 to 158°F) Operating Humidity 5% to 95% Non-condensing Regulatory Approvals EMI FCC Part 15, CISPR (EN55022) class A, EMS IEC61000-4-2 (ESD), IEC61000-4-3 (RS), IEC61000-4-4 (EFT), IEC61000-4-5 (Surge), IEC61000-4-6 (CS), IEC61000-4-8, IEC61000-4-11 Shock IEC60068-2-27 Free Fall IEC60068-2-32 Vibration IEC60068-2-6 Safety EN60950-1, UL508(E331061) MTBF (Hours) (MIL-HDBK-217F2, GB, GC, 25°C ) 370,965 370,965 Warranty 5 years

Industrial 8-port Gigabit Managed Ethernet Switch with 4×10/100/1000T and 4xGigabit Combo port

Overview

IGS-3044GC is managed redundant ring Ethernet switch with 4×10/100/1000Base-T(X) and 4xGigabit Combo ports. With complete support of Ethernet redundancy protocol, O-Ring (recovery time < 30ms over 250 units of connection), Open-Ring, and MSTP/RSTP:2004/STP (IEEE 802.1s/w/D) can protect your mission-critical applications from network interruptions or temporary malfunctions with its fast recovery technology. IGS-3044GC can be managed centralized and convenient by a powerful windows utility — Open-Vision. IGS-3044GC support new DDM (Digital Diagnostic Monitoring) function, which can monitor instantly the status of electrical voltage, current and temperature. The redundant DC power inputs guarantee a non-stop operation. The backup power input will take over immediately when the primary DC power input fails. IGS-3044GC provides relay outputs that can be set up to indicate events with urgency to notify or warn the technicians, so they can quickly respond to the message in priority. Therefore, the switch is one of the most reliable choice for highly-managed and Fiber Ethernet application.

Features

• • Fastest Redundant Ethernet Ring: O-Ring (recovery time < 30ms over 250 units of connection)
  • Open-Ring support the other vendor’s ring technology in open architecture
  • O-Chain allow multiple redundant network rings
  • *note Support standard IEC 62439-2 MRP (Media Redundancy Protocol) function
  • Support Modbus TCP protocol
  • STP/RSTP:2004/MSTP supported
  • Supports PTP Client (Precision Time Protocol) clock synchronization
  • IGMP v2/v3 (IGMP snooping support) for filtering multicast traffic
  • Support IPV6 new internet protocol version
  • Provided HTTPS/SSH protocol to enhance network security
  • Support TACACS+ and 802.1x User Authentication for securityg

Specification

Specifications ORing Switch Model IGS-3044GC Physical Ports 10/100/1000Base-T(X) Ports in RJ45 Auto MDI/MDIX 4 Gigabit Combo Ports with 10/100/1000Base-T(X) and 100/1000Base-X SFP Port 4 Technology Ethernet Standards IEEE 802.3 for 10Base-T IEEE 802.3u for 100Base-TX and 100Base-FX IEEE 802.3z for 1000Base-X IEEE 802.3ab for 1000Base-T IEEE 802.3x for Flow control IEEE 802.3ad for LACP (Link Aggregation Control Protocol) IEEE 802.1p for COS (Class of Service) IEEE 802.1Q for VLAN Tagging IEEE 802.1D for STP (Spanning Tree Protocol) IEEE 802.1D-2004 for RSTP:2004 (Rapid Spanning Tree Protocol 2004) IEEE 802.1w for RSTP(Rapid Spanning Tree Protocol) IEEE 802.1s for MSTP (Multiple Spanning Tree Protocol) IEEE 802.1x for Authentication IEEE 802.1AB for LLDP (Link Layer Discovery Protocol) MAC Table 8192 MAC addresses Priority Queues 4 Processing Store-and-Forward Switch Properties Switching latency : 7 μs Switching bandwidth : 16Gbps Max. Number of Available VLANs : 4096 IGMP multicast groups : 1024 Port rate limiting : User Define Security Features Enable/disable ports, MAC based port security Port based network access control (802.1x) VLAN (802.1Q ) to segregate and secure network traffic Supports Q-in-Q VLAN for performance & security to expand the VLAN space Radius centralized password management SNMPv3 encrypted authentication and access security Https / SSH enhance network security Software Features STP/RSTP:2004/MSTP (IEEE 802.1D/w/s) Redundant Ring (O-Ring) with recovery time less than 30ms over 250 units TOS/Diffserv supported Quality of Service (802.1p) for real-time traffic VLAN (802.1Q) with VLAN tagging and GVRP supported IGMP Snooping for multicast filtering Port configuration, status, statistics, monitoring, security SNTP for synchronizing of clocks over network Support PTP Client (Precision Time Protocol) clock synchronizing Function DHCP Server / Client support Port Trunk support MVR (Multicast VLAN Registration) support Modbus TCP Network Redundancy O-Ring O-Chain Open-Ring STP *note MRP RSTP:2004 MSTP Warning / Monitoring System Relay output for fault event alarming Syslog server / client to record and view events Include SMTP for event warning notification via email Event selection support RS-232 Serial Console Port RS-232 in RJ45 connector with console cable. 9600bps, 8, N, 1 LED Indicators Power Indicator Green : Power LED x 3 R.M. Indicator Green : Indicates that the system is operating in O-Ring Master mode Ring Indicator Green : Indicates that the system is operating in O-Ring mode Fault Indicator Amber : Indicates unexpected event occurred 10/100/1000Base-T(X) RJ45 port Indicator Green for port Link/Act. Amber for 100Mbps indicator 100/1000Base-X SFP port Indicator Green for port Link/Act. Fault Contact Relay Relay output to carry capacity of 1A at 24VDC Power Redundant Input Power Dual DC inputs. 12~48 VDC on 6-pin terminal block Power Consumption (Typ.) 22.8 Watts Overload Current Protection Present Reverse Polarity Protection Present Physical Characteristics Enclosure IP-30 Dimensions (W x D x H) 74.3(W)x109.2(D)x153.6(H) mm (2.93×4.3×6.05 inch) Weight (g) 1075g Environmental Storage Temperature -40 to 85°C (-40 to 185°F) Operating Temperature -40 to 70°C (-40 to 158°F) Operating Humidity 5% to 95% Non-condensing Regulatory Approvals EMI FCC Part 15, CISPR (EN55022) class A EMS IEC61000-4-2 (ESD), IEC61000-4-3 (RS), IEC61000-4-4 (EFT), IEC61000-4-5 (Surge), IEC61000-4-6 (CS), IEC61000-4-8, IEC61000-4-11 Shock IEC60068-2-27 Free Fall IEC60068-2-32 Vibration IEC60068-2-6 Safety EN60950-1 MTBF (Hours) (MIL-HDBK-217F2, GB, GC, 25°C ) 214,978 Warranty 5 years

Industrial 12-port managed Gigabit Ethernet switch with 8×10/100/1000Base-T(X) and 4×100/1000Base-X, SFP socket

IGS-9084GP is managed redundant ring Ethernet switch with 8×10/100/1000Base-T(X) ports and 4×100/1000Base-X SFP ports. The switch is designed for Railway application and fully compliant with the requirement of EN50155/EN50121-4 standard. With completely support of Ethernet Redundancy protocol, O-Ring (recovery time < 30ms over 250 units of connection) and MSTP (RSTP/STP compatible) can protect your mission-critical applications from network interruptions or temporary malfunctions with its fast recovery technology. And support wide operating temperature from -40°C to 75°C. IGS-9084GP can also be managed centralized and convenient by Open-Vision, Except the Web-based interface, Telnet and console (CLI) configuration. In addition, with its rugged design for railway certification, i.e., EN50155/EN50121-4 standard, make IGS-9084GP to be solid and reliable for railway traffic communication and transportation application. Therefore, the switch is one of the most reliable choice for highly-managed and Fiber Ethernet application.

• Support O-Ring (recovery time < 30ms over 250 units of connection) and MSTP(RSTP/STP compatible) for Ethernet Redundancy
• Open-Ring support the other vendor’s ring technology in open architecture
• O-Chain allow multiple redundant network rings
• *note Support standard IEC 62439-2 MRP (Media Redundancy Protocol) function
• Support IEEE 1588v2 clock Synchronization
• Support IPV6 new internet protocol version
• Support ModbusTCP protocol
• Provided HTTPS/SSH protocol to enhance network security
• Supports backup unit device DBU-01 to quickly configuration backup/restore

Specification

Specifications ORing Switch Model IGS-9084GP Rev.2 Physical Ports 10/100/1000Base-T(X) Ports in RJ45 Auto MDI/MDIX 8 100/1000Base-X SFP Port 4 Technology Ethernet Standards IEEE 802.3 for 10Base-T IEEE 802.3u for 100Base-TX and 100Base-FX IEEE 802.3ab for 1000Base-T IEEE 802.3z for 1000Base-X IEEE 802.3x for Flow control IEEE 802.3ad for LACP (Link Aggregation Control Protocol ) IEEE 802.1p for COS (Class of Service) IEEE 802.1Q for VLAN Tagging IEEE 802.1w for RSTP (Rapid Spanning Tree Protocol) IEEE 802.1s for MSTP (Multiple Spanning Tree Protocol) IEEE 802.1x for Authentication IEEE 802.1AB for LLDP (Link Layer Discovery Protocol) MAC Table 8K Priority Queues 8 Processing Store-and-Forward Switch Properties Switching latency: 7 us Switching bandwidth: 24Gbps Max. Number of Available VLANs: 4095 VLAN ID Range : VID 1 to 4094 IGMP multicast groups: 256 for each VLAN Port rate limiting: User Define Jumbo frame Up to 9.6K Bytes Security Featues Device Binding security feature Enable/disable ports, MAC based port security Port based network access control (802.1x) VLAN (802.1Q ) to segregate and secure network traffic Radius centralized password management SNMPv3 encrypted authentication and access security Https / SSH enhance network security Software Features STP/RSTP/MSTP (IEEE 802.1D/w/s) Redundant Ring (O-Ring) with recovery time less than 30ms over 250 units TOS/Diffserv supported Quality of Service (802.1p) for real-time traffic VLAN (802.1Q) with VLAN tagging IGMP Snooping IP-based bandwidth management Application-based QoS management DOS/DDOS auto prevention Port configuration, status, statistics, monitoring, security DHCP Server/Client/Relay SMTP Client Modbus TCP NTP server Network Redundancy O-Ring Open-Ring O-Chain *note MRP MSTP (RSTP/STP compatible) RS-232 Serial Console Port RS-232 in RJ45 connector with console cable. 115200bps, 8, N, 1 LED Indicators Power Indicator (PWR/1/2) Green : Power LED x 3 R.M. indicator (R.M.) Green : indicate system operated in O-Ring Master mode Ring indicator (Ring) Green : indicate system operated in O-Ring mode Fault indicator (Fault) Amber : Indicate unexpected event occurred 10/100/1000Base-T(X) RJ45 port Indicator Green for Link/Act indicator. Amber for duplex indicator 100/1000Base-X SFP port Indicator Green for port Link/Act. Fault Contact Relay Relay output to carry capacity of 1A at 24VDC Power Redundant Input Power Dual DC inputs. 12~48 VDC on 6-pin terminal block (Max. Rating is 60VDC on Rev.2) Power Consumption (Typ.) 12.5 Watts Overload Current Protection Present Physical Characteristics Enclosure IP-30 Dimensions (W x D x H) 74.3 (W) x 109.2 (D) x 153.6 (H) mm (2.93 x 4.3 x 6.05 inch) on Rev.2 Weight (g) 1070 g Environmental Storage Temperature -40 to 85°C (-40 to 185°F) Operating Temperature -40 to 75°C (-40 to 167°F) Operating Humidity 5% to 95% Non-condensing Regulatory Approvals EMI FCC Part 15, CISPR (EN55022) class A, EN50155 (EN50121-3-2, EN55011, EN50121-4) EMS IEC61000-4-2 (ESD), IEC61000-4-3 (RS), IEC61000-4-4 (EFT), IEC61000-4-5 (Surge), IEC61000-4-6 (CS), IEC61000-4-8, IEC61000-4-11 Shock IEC60068-2-27 Free Fall IEC60068-2-32 Vibration IEC60068-2-6 Safety EN60950-1 Warranty 5 years
