1-channel H.264 Industrial Video Encoder with 2 10/100BaseT(X) port, 0 to 60°C operating temperature
The VPort 461 1-channel industrial video encoder with H.264 video compression algorithm provides the best video quality on the market, but with a smaller bandwidth requirement than other video compression standards. In addition, to meet various video stream requirements, the VPort 461 can provide up to 3 video streams simultaneously with H.264 and MJPEG compression format. Video streams can be used for different purposes, such as viewing, recording, and analyzing, and the industrial rugged design, which includes a -40 to 75°C operating temperature, IP30 form factor protection, and industrial certifications, make the VPort 461 suitable
for harsh environments. The VPort 461 is equipped with Moxa’s innovative DynaStream™ function for decreasing the bandwidth consumption of your video transmissions. DynaStream™ can reduce or increase the video frame
rate automatically to make the video stream controllable by the system and system adminstrator.
Rugged Design for Mission-critical Industrial Environments
- -40 to 75°C wide operating temperature
- 2 Ethernet ports for cascade and port redundancy
- 1 RS-232/422/485 COM port for controlling external serial devices over Ethernet
- Redundant 12/24 VDC and 24 VAC power inputs for greater reliability
- Metal housing with IP30 protection against dust
- DIN-Rail mounting installation for industrial environments
- UL60950-1 certified for hazardous locations
- Meets NEMA TS2, Section 2 requirements
Advanced Network Protocols Support Efficient Network Transmission and Integration
- Modbus/TCP for easy communication with SCADA software
- Standard RTSP (real-time streaming protocol) video streaming for easy integration
- Multicast (IGMP) protocols for efficient network transmission
- SNMPv1/v2c/v3 MIB-II for easy network management
- QoS (ToS) for configuring the transmission priority of video streams
- UPnP, DDNS, and IP filtering supported
Two Ethernet Ports for Cascading and Port Redundancy
The VPort 461 has two built-in 10/100 Mbps Ethernet ports for cascading multiple VPort 461 units. With the cascade feature, you’ll need fewer switch ports, and also reduce your cable layout effort. Port redundancy can be used to build a backup path for video transmission in case the primary path is broken.
SD Card for Storing Video Locally when the Network is Down
The VPort 461 is equipped with an SD card socket (V2.0) for local storage purposes. Enable local storage to record events that occur when the network is down and the video stream cannot be transmitted.
Transparent PTZ Control for Easy Control of PTZ Cameras
The VPort 461 uses Moxa’s Real COM technology to implement transparent communication for RS-232/422/485 PTZ control. The benefit of the Transparent PTZ Control function is that it eliminates the need to build the PTZ control driver into the VPort product, allowing the use of a legacy PTZ control panel or keyboard to control a PTZ camera directly.
Feature :
Features and Benefits
- 3 simultaneous video streams for H.264 and MJPEG
- Video latency under 200 ms
- 2 Ethernet ports for cascade and Ethernet port redundancy
- Moxa DynaStream™ function supported for network efficiency
- ONVIF supported for standardization and interoperability
- Local storage capability with SD card slot
- Industrial design with -40 to 75°C operating temperature
- Free VPort SDK PLUS supported
Specification :
| • Video | |
| Video Compression | H.264 (MPEG4 part 10), MJPEG |
| Video Inputs | 1 (BNC connector) |
| Video Outputs | over Ethernet |
| Video Streams | Max. of 3 video streams (2 encoders: 1 for H.264, 1 for H.264 or MJPEG) |
| NTSC/PAL | Auto-sensing or manual |
| Video Resolution and FPS (frames per second) |  |
| Video Viewing | • DynaStream™ supported for changing the video frame rate automatically • Adjustable image size and quality • Timestamp and text overlay • Maximum of 10 simultaneous unicast connections |
| • Audio | |
| Audio Inputs | 1 Line-in or MIC-in with 3.5 mm phone jack |
| Audio Outputs | 1 Line-out with 3.5 mm phone jack |
| Audio Format | Mono, PCM |
| • Network | |
| Protocols | TCP, UDP, HTTP, SMTP, FTP, NTP, DNS, DHCP, UPnP, RTP, RTSP, ICMP, IGMPv3, QoS, SNMPv1/v2c/v3, DDNS, Modbus/TCP |
| Ethernet | 2 10/100BaseT(X) auto negotiating RJ45 ports |
| • Serial Port | |
| PTZ Ports | 1, RS-232/422/485 port (terminal block connector), max. speed of 115.2 Kbps |
| COM Ports | 1, RS-232/422/485 port (DB9 female connector), max. speed of 115.2 Kbps |
| Console Port | 1, RS-232 RJ45 port |
| • GPIO | |
| Digital Inputs | 2, max. 8 mA Low: +13 to +30 V; High: -30 to +3 V |
| Relay Outputs | 2, max. 24 VDC @ 1 A |
| • LED Indicators | |
| PWR1 | Power 1 |
| PWR2 | Power 2 |
| FAULT | Can be configured to correspond to system alarm, power failure, or disconnected network |
| VIDEO | Video input signal |
| PTZ | PTZ control signal |
| SD | SD card operation |
| • Local Storage | |
| SD Socket | Standard SD socket, V2.0 (SDHC) |
| • Power Requirements | |
| Input Voltage | 2 24 VDC/VAC power inputs for redundancy |
| Power Consumption | Approx. 5.5 W |
| • Physical Characteristics | |
| Housing | Metal, IP30 protection |
| Dimensions | 52.98 x 135 x 105 mm (2.09 x 5.31 x 4.13 in) |
| Weight | 900 g |
| Installation | DIN-Rail mounting, wall mounting (with optional kit) |
| • Alarms | |
| Video Motion Detection | Includes sensitivity tuning |
| Video Loss | Video loss alarm |
| Scheduling | Daily repeat timing schedule |
| Imaging | JPEG snapshots for pre/trigger/post alarm images |
| Email/FTP Messaging | Automatic transfer of stored images via email or FTP with event-triggered actions |
| Custom Alarms | HTTP event servers and CGI events for setting customized alarm actions |
| Pre-alarm Buffer | 24 MB for JPEG snapshot images |
| • PAN/TILT/ZOOM | |
| PTZ Camera Control | Via RS-232/422/485 PTZ port or COM port |
| PTZ Control Functions | PAN, TILT, ZOOM, FOCUS, moving speed, preset position (max. 25 positions), and 24 custom commands |
| PTZ Function Updates | Driver upload supported |
| Supported Device Protocols | Pelco D, Pelco P, Dynacolor DynaDome, Cohu, Custom Camera |
| Transparent PTZ Control | Control PTZ cameras with legacy PTZ control panel or keyboard connected to a PC or VPort decoder |
| • Security | |
| Password | User level password protection |
| Filtering | By IP address |
| • Environmental Limits | |
| Operating Temperature | Standard Models: 0 to 60°C (32 to 140°F) Wide Temp. Models: -40 to 75°C (-40 to 167°F) |
| Storage Temperature | -40 to 85°C (-40 to 185°F) |
| Ambient Relative Humidity | 5 to 95% (non-condensing) |
| • Standards and Certifications | |
| Safety | UL 60950-1 |
| EMI | FCC Part 15 Subpart B Class A, EN 55022 Class A |
| EMS | EN 61000-4-2 (ESD), Level 3, EN 61000-4-3 (RS), Level 3, EN 61000-4-4 (EFT), Level 3, EN 61000-4-5 (Surge), Level 3, EN 61000-4-6 (CS), Level 3, EN 61000-4-8, EN 61000-4-11 |
| Traffic Control | NEMA TS2 |
| Shock | IEC 60068-2-27 |
| Freefall | IEC 60068-2-32 |
| Vibration | IEC 60068-2-6 |
| Note | Please check Moxa’s website for the most up-to-date certification status. |
| • MTBF (mean time between failures) | |
| Time | 375,000 hours |
| Database | Telcordia (Bellcore), GB 25°C |
| • Warranty | |
| Warranty Period | 5 years |
| Details | See www.moxa.com/warranty |
| • Minimum Viewing System Requirements | |
| CPU | Pentium 4, 2.4 GHz or above |
| Memory | 512 MB memory or above |
| OS | Windows XP/2000 with SP4 or above, Windows Vista, Windows 7 |
| Browser | Internet Explorer 9.x or above |
| Multimedia | DirectX 9.0c or above |
| • Software Development Kit | |
| VPort SDK PLUS | Includes CGI commands, ActiveX Control, and API library for customized applications or system integration for third-party developers (the latest version of SDK is available for download from Moxa’s website). |
| Standard | ONVIF |
