ATEN CE610 USB 2.0 DVI KVM Extender

Posted on by

ATEN CE610-1

The CE610 USB 2.0 DVI KVM Extender is a DVI and USB Extender that supports USB 2.0, HDBaseT technology, USB touch panels, and file transfer functionality.

ATEN CE610-2

With HDBaseT support, the CE610 USB 2.0 DVI KVM Extender uses only one Cat 5e cable to extend DVI and USB signals up to 100 m. The CE610 is equipped with USB connectors which allow you to extend any USB device between the units. The USB functionality provides not only peripheral sharing but also provides support for touch panel control and fi le transfer. The CE610 is ideal for situations where touch panel is required, such as transportation centers, medical facilities, shopping malls,and when synchronizing for fi les/ folders between portable and desktop computers are required.

Feature :

  • Uses single Cat 5e cable to connect the local and remote units
  • Allow access to a computer or KVM installation from a remote console
  • Superior Video Quality – up to 1920 x 1200 @ 60 Hz at 100 m
  • Supports HDBaseT connectivity technology
  • Transparent USB Support – supports all USB 2.0 High Speed device*
  • Extends local PC Video/Keyboard/Mouse to Remote side
  • Built-in 8KV/15KV ESD protection (Contact voltage 8KV; Air voltage 15KV)
  • USB 2.0 Support*: supports devices such as keyboard, mouse, fl ash drive, printer, microphone, speakers, USB web cameraand other USB 1.1 devices which require moderate amounts of bandwidth* Note: The CE610 supports USB transfer rates of up to 30 Mbps.

Diagram :

Diagram CE610

Specification :

Function CE610L CE610R
Connectors DVI In 1 x DVI-D Female (White) N/A
DVI Out N/A 1 x DVI-D Female (White)
USB 1 x USB Type B Female (White) 3 x USB Type A Female (White)
Power 1 x DC Jack
F/W Upgrade 1 x RJ-11 Female (Black)
Unit to Unit 1 x RJ-45 Female (Black)
LEDs Power 1 (Green)
Link 1 (Green)
USB 1 (Green)
Video 1 (Green)
Emulation Keyboard / Mouse USB
Video 1920 x 1200 @ 60Hz (100 m)
Power Consumption DC 5V, 15 W
Environment Operating Temp. 0–50°C
Storage Temp. -20–60°C
Humidity 0–80% RH, Non-condensing
Physical
Properties		 Housing Metal
Weight 605g 615g
Dimensions
(L x W x H)		 18.20 x 11.79 x 2.28 cm
  • The specification and pictures are subject to change without notice.
  • All trademarks and logos are the properties of their respective holders.

ATEN CE604 DVI Dual View KVM Extender

Posted on by

ATEN CE604-1

The CE604 is a DVI Dual View USB based KVM Extender that features Dual View functionality, which enables the video output to seamlessly display on two monitors. With RS-232 serial functionality, it allows access to a computer system from a remote console up to 60 m away. The CE604 is built for control and security purposes, and is targeted towards financial and industrial markets.

ATEN CE604-2

The CE604 is equipped with an RS-232 serial channel that connects to a serial terminal or to serial devices, such as touch screens and barcode scanners. In addition, it supports an advanced PC Wake Up feature, which allows you to simply press a pushbutton from the remote dual view console to wake a PC at the local site. The CE604 eliminates the need for traveling back and forth between the local computer and remote console, making it an effi cient and flexible solution.
The CE604 is ideal for applications that require the console to be in a conveniently accessible location, while the system equipment needs to reside in a safe place – away from dust, dirt and harsh environmental influences. It also provides a cost-effective way of keeping sensitive data, such as financial and personal information, safe in a heavily
secured data center, while still allowing remote access to users.

Feature :

  • Local and Remote Units connect at distances up to 60 m using two Cat 5e cables
  • Transmit speaker, keyboard, mouse, DDC and one DVI via one Cat5 cable; RS-232, microphone and another DVI by adding a second Cat 5e cable
  • Supports Dual View video source transmission (one PC with two video output ports)
  • Audio Enabled – supports stereo speakers and microphone
  • Supports Real DDC bypass and ATEN default EDID technology – set up various confi gurations via hotkeys
  • Supports PC wakeup function via one pushbutton or hotkey
  • RS-232 serial channel – connect to a serial terminal, or serial devices such as touchscreens and barcode scanners (Baud Rate up to 9600 bps)
  • Compatible with other ATEN Dual View KVM devices, such as CS1642A/ CS1644A and CS1762A/CS1764A
  • Superior video quality – up to 1920 x 1200 @ 60 Hz at 30 m; 1024 x 768 @ 60 Hz at 60 m
  • Manual compensation control to adjust video signal quality in order to compensate for distance
  • Built-in 8KV/15KV ESD protection (Contact voltage 8KV; Air voltage 15KV) and 2KV surge protection

Diagram :

Diagram CE604

Specification :

Function CE604L CE604R
Connectors KVM Ports USB 1 x USB Type B Female (White) N/A
Speakers 1 x Mini Stereo Jack Female (Green) N/A
Mic. 1 x Mini Stereo Jack Female (Pink) N/A
Video input 2 x DVI-D Female (White) N/A
Console Ports Video N/A 2 x DVI-D Female (White)
Speakers N/A 1 x Mini Stereo Jack Female (Green)
Mic. N/A 1 x Mini Stereo Jack Female (Pink)
Keyboard N/A 1 x USB Type A Female (White)
Mouse N/A 1 x USB Type A Female (White)
RS-232 1 x DB-9 Female (Black) 1 x DB-9 Male (Black)
Power 1 x DC Jack (Black)
Sub / Main 2 x RJ-45 Female (Black)
LEDs Link 1 (Green) 1 (Green)
Power 1 (Green) 1 (Green)
Switches Compensation switch N/A 2 x 8-position switch
F/W Upgrade 1 x Slide Switch N/A
Buttons Wakeup button N/A 1 x pushbutton
Video 1920×1200 @ 60Hz (30 m); 1024×768 @ 60Hz (60 m)
Power Consumption DC5.3V, 3.4W D5.3V, 4.3W
Environment Operating Temp. 0–50°C
Storage Temp. -20–60°C
Humidity 0–80% RH, Non-condensing
Physical
Properties		 Housing Metal
Weight 0.48 kg
Dimensions
(L x W x H)		 20.20 x 8.54 x 2.50 cm 20.20 x 8.70 x 2.50 cm
  • The specification and pictures are subject to change without notice.
  • All trademarks and logos are the properties of their respective holders.

ATEN CE602 DVI Dual Link KVM Extender

Posted on by

Aten CE602-1

The CE602 is a DVI Dual Link and USB based KVM Extender with RS-232 serial functionality. It allows access to a computer system from a remote console (USB keyboard, monitor, and mouse). Because it allows access to a computer system from a remote console, the CE602 is perfect for use in any type of installation where you need to place the console where it is conveniently accessible, but you want the system equipment to reside in a safe location – away from the dust and dirt of the factory floor, or the harsh environmental influence of a construction site, for example. This allows users to deploy system equipment over large distances.

Aten CE602-2

The CE602 can support up to 2560 x 1600 (DVI Dual Link) resolution. It uses two Cat 5e cables for HDCP, RS-232, microphone and dual link signals. You can also use just one Cat 5e cable if using single link connections.

Feature :

  • Local and Remote Units connect at distances up to 60 m using Cat 5e cable
  • Allows access to a computer or KVM installation from a remote console (up to 60 m)
  • Supports DVI-D interface and allows transmission of DVI duallink signals
  • Features ATEN technology that allows A/V transmission over one cat 5e cable
  • The 2nd Cat 5e cable is used for HDCP, RS-232, microphone and dual link signals
  • Manual compensation control to adjust signal strength in order to compensate for distance
  • RS-232 serial ports – connect to a serial terminal, or serial devices such as touchscreens and barcode scanners (Baud Rate 115200 bps)
  • Audio Enabled – supports stereo speakers and microphone
  • Built-in 8KV/15KV ESD protection (Contact voltage 8KV; Air voltage 15KV)
  • Supports Wide Screen formats
  • Superior video quality of up to 2560 x 1600 @ 60 Hz (DVI Dual Link) at 40 m; 1920 x 1200 @ 60 Hz at 30 m; 1024 x 768 @ 60 Hz at 60 m – get an excellent, crisp image on your screen over long distance transmissions
  • Hot pluggable
  • Rack mountable
  • Easy to install – no software required – connecting cables to the devices is all it takes
  • Firmware upgrade

Diagram :

Diagram CE602

Specification :

Function CE602L CE602R
Connectors Console
Ports		 Keyboard N/A 1 x USB Type A Female (White)
Video N/A 1 x DVI-D Female (White)
Mouse N/A 1 x USB Type A Female (White)
Speakers N/A 1 x Mini Stereo Jack Female (Green)
Mic. N/A 1 x Mini Stereo Jack Female (Pink)
KVM
Ports		 Video 1 x DVI-D Female (White) N/A
Speakers 1 x Mini Stereo Jack
Female (Green)		 N/A
Mic. 1 x Mini Stereo Jack
Female (Pink)		 N/A
USB 1 x USB Type B Female
(White)		 N/A
RS-232 1 x DB-9 Female (Black) 1 x DB-9 Male (Black)
Power 1 x DC Jack
Sub/Main 2 x RJ-45 Female (Black)
LEDs Link 1 (Green)
Power 1 (Green)
Switches EQ Switch N/A 1 x 8-position switch
Firmware Upgrade 1 x Slide Switch N/A
Emulation Keyboard/Mouse USB
Video 2560 x 1600 @ 60Hz (40 m)
1920 x 1200 @ 60Hz (30 m);
1024 x 768 @ 60Hz (60 m);
Power Consumption DC 5.3V/3.18 W DC5.3V, 5.04 W
Environment Operating Temp. 0–50°C
Storage Temp. -20–60°C
Humidity 0–80% RH, Non-condensing
Physical Properties Housing Metal
Weight 0.48 kg
Dimensions
(L x W x H)		 20.20 x 8.54 x 2.50 cm 20.20 x 8.70 x 2.50 cm



  • The specification and pictures are subject to change without notice.
  • All trademarks and logos are the properties of their respective holders.

ATEN CE600 DVI KVM Extender

Posted on by

Aten CE600-1

The CE600 is a DVI and USB based KVM Extender with RS-232 serial functionality. It allows access to a computer system from a remote console (USB keyboard, monitor, and mouse). Because it allows access to a computer system from a remote console, the CE600 is perfect for use in any type of installation where you need to place the console where it is conveniently accessible, but you want the system equipment to reside in a safe location – away from the dust and dirt of the factory floor, or the harsh environmental infl uence of a construction site, for example. This allows users to deploy system equipment over large distances.

Aten CE600-2

The CE600 users one Cat 5e cable (DVI Single Link) to support up to 1920 x 1080 video resolution *
* The 2nd Cat 5e cable is used for HDCP, RS-232, and microphone signals.

Feature :

  • Local and Remote Units connect at distances up to 60 m using Cat 5e cable
  • Allows access to a computer or KVM installation from a remote console (up to 60 m)
  • Features ATEN technology that allows A/V transmission over one cat 5e cable
  • The 2nd Cat 5e cable is used for HDCP, RS-232, and microphone signals
  • Manual compensation control to adjust signal strength in order to compensate for distance
  • RS-232 serial ports – connect to a serial terminal, or serial devices such as touchscreens and barcode scanners (Baud Rate 115200 bps)
  • Audio Enabled – supports stereo speakers and microphone
  • Built-in 8KV/15KV ESD protection (Contact voltage 8KV; Air voltage 15KV)
  • Supports Wide Screen formats
  • Superior video quality of up to 1920 x 1200 @ 60 Hz at 30 m; 1024 x 768 @ 60 Hz at 60 m – get an excellent, crisp image on your screen over long distance transmissions
  • Hot pluggable
  • Rack mountable
  • Easy to install – no software required – connecting cables to the devices is all it takes
  • Firmware upgrade

Diagram :

Diagram CE600

Specification :

Function CE600L CE600R
Connectors Console
Ports		 Keyboard N/A 1 x USB Type A Female (White)
Video N/A 1 x DVI-D Female (White)
Mouse N/A 1 x USB Type A Female (White)
Speakers N/A 1 x Mini Stereo Jack Female (Green)
Mic. N/A 1 x Mini Stereo Jack Female (Pink)
KVM
Ports		 Video 1 x DVI-D Female (White) N/A
Speakers 1 x Mini Stereo Jack
Female (Green)		 N/A
Mic. 1 x Mini Stereo Jack
Female (Pink)		 N/A
USB 1 x USB Type B Female
(White)		 N/A
RS-232 1 x DB-9 Female (Black) 1 x DB-9 Male (Black)
Power 1 x DC Jack
Sub/Main 2 x RJ-45 Female (Black)
LEDs Link 1 (Green)
Power 1 (Green)
Switches EQ Switch N/A 1 x 8-position switch
Firmware Upgrade 1 x Slide Switch N/A
Emulation Keyboard/Mouse USB
Video 1920 x 1200 @ 60Hz (30 m);
1024 x 768 @ 60Hz (60 m);
Power Consumption DC5.3V/2.65 W DC5.3V, 4.24 W
Environment Operating Temp. 0–50°C
Storage Temp. -20–60°C
Humidity 0–80% RH, Non-condensing
Physical Properties Housing Metal
Weight 0.48 kg
Dimensions
(L x W x H)		 20.20 x 8.54 x 2.50 cm 20.20 x 8.70 x 2.50 cm
  • * The specification and pictures are subject to change without notice.
  • * All trademarks and logos are the properties of their respective holders.

ATEN CE790 Digital KVM Extender

Posted on by

ATEN CE790-1

The CE790 is a IP based KVM Extender with automatic cable detection (Auto-MDIX) and RS-232 serial functionality that allows access to a computer system from a remote USB console (USB keyboard, monitor, and USB mouse) anywhere on the intranet.

ATEN CE790-2

The CE790 improves on previous designs by: 1) the addition of an intuitive On Screen Display (OSD) on both the transmitter and receiver units for easy setup and operation; 2) working over a standard TCP/IP LAN via inexpensive Cat 5e cable, allowing point-to-point, point-to-multipoint, and multipoint-to-multipoint administration without the need for an additional KVM switch; and 3) the addition of an RS-232 port, on both the transmitter and receiver Units – to connect to a serial terminal for configuration, and serial devices such as touchscreens and barcode scanners. * The CE790 can be installed in point to point, point to multipoint and multipoint to multipoint configurations. Multipoint configurations require a separate purchase – contact your delear for details.

ATEN CE790-3

* In multipoint configurations, the IGMP (Internet Group Management Protocol) function of your network switches/hubs should be enabled to avoid deterioration of data throughput. If you do not know how to enable IGMP, please contact your network administrator.

Feature :

  • Remotely access computers on your KVM installation via intranet
  • Dual console operation – control your system from both the transmitter and receiver USB consoles
  • OSD (On Screen Display) on both the transmitter and receiver units
  • Supports GUI operation*
  • No software required – an HTTP server is embedded in both units
  • Built-in ASIC for greater reliability and compatibility
  • USB Keyboard and USB Mouse Ports
  • RS-232 serial ports** – allows you to connect to a serial terminal for configuration, or serial devices such as touchscreens and barcode scanners
  • Audio enabled
  • USB overcurrent detection and prevention
  • High resolution video – up to 1920 x 1080
  • Supports widescreen formats
  • Ultra-High quality video mode
  • Hot pluggable
  • Rack mountable
  • Firmware upgradable
  • Auto-MDIX – automatically detects cable type

    Note:
    * The CE790 AP and GUI operation instructions can be downloaded from the ATEN website (www.aten.com).
    ** RS-232 serial ports support Tx/Rx/CTS/RTS signals only.

Diagram :

Diagram CE790

Specification :

Console Connectors
Monitor 1 x HDB-15 (F)
Keyboard 1x USB type A (F)
Mouse 1x USB type A (F)
Audio 1 x Mini Stereo Jack (F)
Microphone 1 x Mini Stereo Jack (F)
Connectors
RS-232 2 x DB9 (1M / 1F)
Power 1 x DC Jack
KVM Side Connections
Keyboard, Video, Mouse 1 x SPHD-15 (F)
Audio 1 x Mini Stereo Jack (F)
Microphone 1 x Mini Stereo Jack (F)
LAN Connection 1 x RJ-45 (F)
Switches
Mode Selection 1 x Pushbutton ( OSD)
Port Selection 1 x Pushbutton
Emulation
Keyboard USB
Mouse USB
Video connections
Input VGA
Output VGA
Video Resolution Up to 1920 x 1080
Power Adaptor Part #
for North America 0AD8-0605-24EG
for Continental Europe 0AD6-1605-241G
for UK 0AD4-3605-241G
Environment
Operation Temperature 32-122 F
Storage Temperature 25 ~ 140 F
Humidity 0 ~ 80% RH, Non-condensing
Housing
Case Metal
Physical Properties
Unit Weight 2.2 lbs (R + T)
Case Qty 5
Case Weight 11.2 lbs
Case Dimension 20x 13.5x 9.2 in.
Unit Package Dimensions 13x 4x 8.5 in.
Unit Weight with package 2.1 lbs
Unit Dimension 7.8x 3.1x 1 in.
