ATEN CS19208 8-Port USB 3.0 4K DisplayPort KVM Switch

• One USB console controls up to eight DisplayPort interface computers and two additional USB 3.0 peripheral devices
• Cascadable to two levels – controls up to 128 computers¹
• Multi-Display feature – stack up to eight CS19208 units and display video from up to 8 monitors (dual display / triple display / quad display / multi-display)
• Video DynaSync™ – an exclusive ATEN technology that eliminates boot-up display problems and optimizes the resolution when switching among different sources
• EDID Expert™ – selects optimum EDID mode for smooth power-up and highest quality display
• Supports a DisplayPort or HDMI video output – allows you to choose an appropriate video output and deploy console with flexibility
• Superior video quality – up to 4K DCI (4096 x 2160 @ 60Hz)
• Built-in 2-port USB 3.1 Gen 1 hub with SuperSpeed 5 Gbps data transfer rates
• Audio enabled – full bass response provides a rich experience for 2.1 channel stereo sound
• Supports HD audio²
• Computer selection via pushbuttons, hotkeys, OSD, and RS-232 commands
• Independent switching of KVM and USB peripheral focus³
• Two-level (administrator/user) password authorization for enhanced security protection
• Broadcast mode – operations can be simultaneously performed on all selected computers, such as software installation and upgrading, system-wide shutdown, etc.
• Auto Scan Mode for monitoring all computers
• Console mouse port emulation/bypass feature supports most mouse drivers and multifunction mice
• Multilingual keyboard mapping – supports English (US), English (UK), German (GER.), German (SWISS), French, Hungarian, Italian, Japanese, Korean, Russian, Spanish, Swedish, Traditional Chinese, and Simplified Chinese
• Mac/Sun keyboard support and emulation⁴
• Supports hot-plugging
• DisplayPort 1.2 compliant; HDCP 2.2 compliant
• Multiplatform support – Windows, Linux, Mac, and Sun
• Firmware upgradable
• Supports multimedia, wireless keyboards and mouse

Package Contents

• 1x CS19208 8-Port USB 3.0 4K DisplayPort KVM Switch with Rack Mounting Kit
• 2x DisplayPort 1.4 Cables
• 2x USB 3.0 Cables
• 2x Audio Cables
• 1x Firmware Upgrade Cable
• 1x Foot Pad Set (4 pcs)
• 1x Power Adapter
• 1x User Instructions

ATEN CV190 DisplayPort Console Converter

• Connects an ATEN SPHD-interfaced KVM switch to a DisplayPort and USB-enabled target computer
• Supports high video resolution – up to 1920 x 1080 @ 60Hz
• DisplayPort 1.1 compliant
• Supports USB keyboard and mouse
• Bus-powered – no external power adapter required
• Easy installation – no software required

Package Contents

• 1x CV190 DisplayPort console converter cable

ATEN VS381 3-Port True 4K HDMI Switch

• Allows up to 3 HDMI input sources to be transmitted to 1 HDMI output display
• Superior video quality – True 4K resolution of 4096 x 2160 / 3840 x 2160 @ 60Hz (4:4:4) up to 5m; HDR supported
• HDMI (3D, Deep Color, 4K, HDR10+, Dolby Vision, HLG)
• HDCP 2.2 compliant
• Auto switching mode for auto port selection
• Switching between HDMI input sources via front panel pushbuttons and IR remote control
• Supports IR extension
• Supports 7.1 channel audio output
• Clear LED indication of device status
• Plug-and-play – no software installation required

Package Contents

• 1x VS381B 3-Port True 4K HDMI Switch
• 1x USB to DC Power Cord
• 1x IR Remote Control
• 1x IR Receiver
• 1x User Instructions

ATEN UC485 USB to RS-422/485 Adapter

• Converts a USB port to a Legacy RS-422 or RS-485 COM port
• Fast COM Port Transmission – up to 921.6 Kbps
• Package included DB-9 female to terminal block adapter for easy wiring
• Supports Terminal / ECHO mode by mode selector
• Supports Windows Vista / 7 and above, Mac and Linux
• Plug-and-Play – no power supply needed

Package Contents

• 1x UC485 USB to RS-422/485 Adapter
• 1x Terminal Adapter
• 1x User Instructions
