ATEN VS172 DVI Dual Link Splitter with Audio

Posted on by

VS172The VS172 2-Port DVI Dual Link Splitter with Audio combines DVI quality video and audio, taking signals from an audio/ video source and replicating them to two audio/video outputs. This video splitter uses dual link technology, which offers high bandwidth capacity for added transmission power and faster refresh rates, thereby providing better video quality of viewing resolutions up to 2560 x 1600.

VS172-1

The built-in bi-directional RS-232 port on the rear panel allows the splitter to be controlled through a Control Unit, PC, and/or home automation/home theater software package for complete system integration.

VS172-2

The VS172 is easy to operate and can be cascaded to three levels, handling up to 8 monitors, which makes them the ideal solution for situations such as:
a) Broadcasting video information to the public (news headlines,stock prices, airline and train schedules, etc.)
b) Company training facilities
c) Classroom instruction

Feature :

  • Displays DVI audio/video to multiple DVI-compatible monitors or projectors
  • Superior video quality – up to 2560 x 1600 @ 60 Hz including 2K-resolution (2048 x 2048 @ 60 Hz)
  • Cascadable to 3 levels – provides up to 8 video signals
  • Audio enabled
  • Features RS-232 serial port for command controls
  • RS-232 Chain Control – use RS-232 commands to control cascaded devices via a DVI Cable
  • EDID Expert – selects the optimum EDID settings via RS-232* Note: The VS172 AP and GUI operation instructions can be downloaded from the ATEN website (www.aten.com)

Diagram :

Diagram VS172

Specification :

Computer Connections 2
Connectors Video In 1 x DVI-D Female (White)
Audio In 1 x Mini Stereo Jack (Green)
RS-232 1 x DB 9 Female (Black)
Video Out 2 x DVI-D Female (White)
Audio Out 2 x Mini Stereo Jacks (Green)
Power 1 x DC Jack
LEDs Link 1 (Green)
Power 1 (Green + Orange)
Resolution Up to 2560 x 1600
Power Consumption DC5.3V, 3.1W
Signal Range 5 m (15 ft)
Environment Operating Temp. 0-50°C
Storage Temp. -20-60°C
Humidity 0–80% RH, Non-condensing
Physical
Properties		 Housing Metal
Weight 0.68 kg
Dimensions
(L x W x H)		 21.00 x 8.80 x 5.55 cm
  • The specification and pictures are subject to change without notice.
  • All trademarks and logos are the properties of their respective holders.

ATEN VS1808T 8-Port HD Video/Audio Cat5e/6 Splitter with RS-232

Posted on by

ATEN VS1808T-1

The ATEN VS1808T HDMI Over Cat 5 Splitter is the quickest and most efficient way to move HDMI multimedia content and HDCP information from input source to 8 displays. A one-to-many, point-to-multipoint system for transmission of high definition video and audio, the VS1808T transmits rich multimedia content in real time from HDMI source devices to HDMI display devices over Cat 5e cables. The VS1808T can support multi-displays when combined in an installation with ATEN’s HDMI extender*.

ATEN VS1808T-2

The VS1808T provides the flexibility you need for a customized digital signage or HDMI display installation, allowing you to set up your display device 60 m (200 ft) from the HDMI source devices. The VS1808T solution is ideal for any installation that requires HDMI content to be delivered to multiple destinations, such as: • In-store or tradeshow digital signage • Broadcasting information to public locations (news, airline and train schedule and arrival/departure information) • Sporting events • Theater and lecture overview rooms • Classroom and company training facilities Note*: Compatible receiving device is VE800R

Feature :

  • One HDMI input to 8 HDMI outputs via Cat 5e cables
  • Extends displays up to 198 ft
  • Supports HDMI (3D, Deep color)
  • Offers local HDMI output
  • HDCP compatible
  • Consumer Electronics Control (CEC) allows interconnected HDMI devices to communicate and respond to one remote control
  • Cascadable to three levels
  • Supports superior video quality – HDTV resolutions of 480p, 720p, 1080i and 1080p (1920 x 1080)
  • EDID mode selection
  • Rack-mountable

Diagram :

Diagram VS1808T

Specification :

Connectors HDMI In 1 x HDMI Type A Female (Black)
HDMI Out Local 1 x HDMI Type A Female (Black)
Line Out
(Cat 5)		 TMDS 8 x RJ-45 Female
DDC 8 x RJ-45 Female
RS-232 1 x DB-9 Female (Black)
Power 1 x DC Jack
Switches EDID Mode 1 x 8-Position Switch
EDID Learn Mode 1 x Pushbutton
LEDs Power 1 (Green)
HDMI In 1 (Green)
HDMI Out 1 (Green)
EDID Learn 1 (Green / Red)
Line Out 8 (Green)
Video 1080p @ 130 ft; 1080i @ 198 ft
Power Consumption DC5.3V, 13W
Environment Operating Temp. 0-50°C
Storage Temp. -20-60°C
Humidity 0-80% RH, Non-condensing
  •  The specification and pictures are subject to change without notice.
  • All trademarks and logos are the properties of their respective holders.

ATEN VS1804T 4-Port HD Video/Audio Cat5e/6 Splitter with RS-232

Posted on by

ATEN VS1804T-1

The ATEN VS1804T HDMI Over Cat 5 Splitter is the quickest and most efficient way to move HDMI multimedia content and HDCP information from input source to 4 displays. A one-to-many, point-to-multipoint system for transmission of high definition video and audio, the VS1804T transmits rich multimedia content in real time from HDMI source devices to HDMI display devices over Cat 5e cables. The VS1804T can support multi-displays when combined in an installation with ATEN’s HDMI extender*.ATEN VS1804T-2

The VS1804T provides the flexibility you need for a customized digital signage or HDMI display installation, allowing you to set up your display device 60 m (200 ft) from the HDMI source devices. The VS1804T solution is ideal for any installation that requires HDMI content to be delivered to multiple destinations, such as: • In-store or tradeshow digital signage • Broadcasting information to public locations (news, airline and train schedule and arrival/departure information) • Sporting events • Theater and lecture overview rooms • Classroom and company training facilities Note*: Compatible receiving device is VE800R

Feature :

  • One HDMI input to 4 HDMI outputs via Cat 5e cables
  • Extends displays up to 198 ft
  • Supports HDMI (3D, Deep color)
  • Offers local HDMI output
  • HDCP compatible
  • Consumer Electronics Control (CEC) allows interconnected HDMI devices to communicate and respond to one remote control
  • Cascadable to three levels
  • Supports superior video quality – HDTV resolutions of 480p, 720p, 1080i and 1080p (1920 x 1080)
  • EDID mode selection
  • Rack-mountable

Diagram :

Diagram VS1804T

Specification :

Connectors HDMI In 1 x HDMI Type A Female (Black)
HDMI Out Local 1 x HDMI Type A Female (Black)
Line Out
(Cat 5)		 TMDS 4 x RJ-45 Female
DDC 4 x RJ-45 Female
RS-232 1 x DB-9 Female (Black)
Power 1 x DC Jack
Switches EDID Mode 1 x 8-Position Switch
EDID Learn Mode 1 x Pushbutton
LEDs Power 1 (Green)
HDMI In 1 (Green)
HDMI Out 1 (Green)
EDID Learn 1 (Green / Red)
Line Out 4 (Green)
Video 1080p @ 130 ft; 1080i @ 198 ft
Power Consumption DC5.3V, 8W
Environment Operating Temp. 0-50°C
Storage Temp. -20-60°C
Humidity 0-80% RH, Non-condensing
Physical
Properties		 Housing Metal
Weight 4.6 lb (2.10 kg)
Dimensions
( L x W x H )		 17 x 6.1 x 1.7 in.(43.24 x 15.41 x 4.40 cm)
  • The specification and pictures are subject to change without notice.
  • All trademarks and logos are the properties of their respective holders.

ATEN VS1208T Over Cat 5 Video Splitter

Posted on by

ATEN VS1208T-1

The VS1208T A/V Over Cat 5 Splitter is a cost-effective and efficient solution for sending high quality audio and video content to multiple displays. Connect to an ATEN A/V Over Cat 5 Receiver* via Cat 5e cable and the displays can be located up to 300 m (1000 ft) away from the single input source.

ATEN VS1208T-2

The VS1208T A/V Over Cat 5 Splitter is ideal for any professional A/V installation that requires multimedia content to delivered to multiple destinations.

Compatible Receiver Units:
VE170R A/V Over Cat 5 Receiver
VE170RQ A/V Over Cat 5 Receiver with Deskew

Feature :

  • One audio/video input to 8 audio/video outputs via Cat 5e cable
  • Supports local display + 8 remote displays
  • Supports up to 225 MHz bandwidth
  • Uses Cat 5e cable to extend displays up to 300 m
  • Superior video quality – up to 1920 x 1200@60Hz
  • Audio enabled (mono)
  • Built-in 8KV/15KV ESD protection
  • Rack-mountable

Diagram :

Diagram VS1208T

Specification :

Specification VS1208T

ATEN VS1204T Over Cat 5 Video Splitter

Posted on by

ATEN VS1204T-1

The VS1204T A/V Over Cat 5 Splitter is a cost-effective and efficient solution for sending high quality audio and video content to multiple displays. Connect to an ATEN A/V Over Cat 5 Receiver* via Cat 5e cable and the displays can be located up to 300 m (1000 ft) away from the single input source.

ATEN VS1204T-2

The VS1204T A/V Over Cat 5 Splitter is ideal for any professional A/V installation that requires multimedia content to delivered to multiple destinations.

Compatible Receiver Units:
VE170R A/V Over Cat 5 Receiver
VE170RQ A/V Over Cat 5 Receiver with Deskew

Feature :

  • One audio/video input to 4 audio/video outputs via Cat 5e cable
  • Supports local display + 4 remote displays
  • Supports up to 225 MHz bandwidth
  • Uses Cat 5e cable to extend displays up to 300 m
  • Superior video quality – up to 1920 x 1200@60Hz
  • Audio enabled (mono)
  • Built-in 8KV/15KV ESD protection
  • Rack-mountable

Diagram :

Diagram VS1204T

Specification :

Specification VS1204T
