ATEN CL6700MW DVI Full HD LCD Console

Posted on December 22, 2014 by

The CL6700MW DVI Full HD LCD Console is a single rail KVM console featuring a 17.3’’ high-definition widescreen with an integrated keyboard and touchpad in a 1U rack-mountable sliding housing. The CL6700MW’s console provides front end access to compatible KVM switches utilizing space with a module that closes fl at and slides into the rack. The single rail design allows the LCD monitor, keyboard and touchpad to operate independently of each other. Multiple video ports allow the console to connect one of three types of video sources: VGA, DVI, or HDMI – for the console and CPU connection. For added convenience, the full HD console provides two HDMI ports that allow for connecting a high-defi nition monitor to the console port, and/or an HDMI compatible switch to the KVM port.

CL6700MW-2 The CL6700MW features a port for an external USB mouse on the unit’s front panel, while ports for the second KVM console (keyboard, mouse and DVI, HDMI or VGA monitor) are provided on the rear panel. Server rooms already installed with compatible DVI KVM switches will have the advantage of easy access, an additional console, and a built-in space saving sliding module, without having to purchase a KVM switch.The CL6700MW includes two mini stereo ports for connecting audio speakers.

Feature :

Integrated KVM console with a 17.3” Widescreen Full HD LCD monitor in a single rail housing with top and bottom clearance for smooth operation in a 1U high system rack
Standard rack mount kit included – optional Easy Rack Mounting (single person installation) rack mount kit available (requires separate purchase)
Supports an external console with USB / DVI / VGA / HDMI connectors
Additional hot-pluggable USB mouse port on front panel (also functions as USB peripheral port)
Superior video quality – up to 1920 x 1080 @ 60Hz; DDC, DDC2, DDC2B
Audio support for connecting speakers
Standard 105-key keyboard; Sun keyboard emulation
Multiplatform support – Windows, Linux, Mac, and Sun
Adjustable depth to fi t within the rack
Firmware upgradeable
Console lock – enables the console drawer to remain securely locked away in position when not in use
DDC emulation – video settings of attached computers are automatically adjusted for optimal output to the monitor
Keyboard Language support: English(US); English(UK); German;German(Swiss); French; Spanish; Traditional Chinese; Japanese; Korean;Swedish; Italian; Russian; Hungarian; Greek

Diagram :

Diagram CL6700MW

Specification :

Computer Connections			1
Console Selection			Hotkey
Connectors	External Console Ports	Keyboard	1 x USB Type A Female
		Mouse	1 x USB Type A Female
		Monitor	1 x DVI-D Female (White) 1 x HDB-15 (VGA) Female (Blue) 1 x HDMI Female (Black)
		Speaker	1 x Mini Stereo Jack Female (Green)
	KVM Ports	Keyboard / Mouse	1 x USB Type B Female (White)
		Monitor	1 x DVI-D Female (White) 1 x HDB-15 (VGA) Male (Blue) 1 x HDMI Female (Black)
		Speaker	1 x Mini Stereo Jack Female (Green)
	External Mouse / Peripheral		1 x USB Type A Female (Black)
	Firmware Upgrade		1 x RJ-11 Female (Black)
	Power		1 x 3-prong AC Socket
Switches	Reset		1 x Semi-recessed Pushbutton
	Power		1 x Rocker
	F/W Upgrade		1 x Slide
	LCD Power		1 x Pushbutton
	LCD Adjustment		4 x Pushbutton
LEDs	Power		1 (Green)
	Lock	Num	1 (Green)
		Caps	1 (Green)
		Scroll	1 (Green)
Emulation	Keyboard / Mouse		USB
Video			1920 x 1080 @ 60Hz, DDC2B
I/P Rating			100–240VAC; 50–60Hz; 1A
Power Consumption			120V,19.4W / 230V,19.4W
Environment	Operating Temp.		0-40°C
	Storage Temp.		-20-60°C
	Humidity		0 – 80% RH, Non-condensing
Physical Properties	Housing		Metal
	Weight		11.38 kg
	Dimensions (L x W x H)		58.92 x 48.00 x 4.40 cm

The specification and pictures are subject to change without notice.
All trademarks and logos are the properties of their respective holders.

ATEN CL1316N 19” LCD KVM Switch

Posted on December 17, 2014 by

With limited server room space and rising maintenance costs, network administrators are now more than ever looking for solutions that reduce both costs and space requirements. ATEN LCD KVM Switches offer a space saving, streamlined approach to KVM switching technology by integrating an LCD panel, full keyboard, and touchpad into a 1U rack-mountable sliding housing. The CL1316 LCD KVM Switch features an integrated 19″ LCD panel allowing access and control with up to 16 computers from a single console (keyboard, mouse, and monitor). As many as 16 additional switches can be cascaded bringing the total number of connected computers to 256 computers that can be controlled from a single keyboard-monitor-mouse console.

CL1316-2 Setup is fast and easy; plugging cables into their appropriate ports is all that is needed. The switch supports both USB and PS/2 connections for the computers. The CL1316 intercepts keyboard input directly, thus eliminating the need for any software configuration. Switching between computers can be easily accomplished either by manually pressing the front panel push button port LEDs, entering hotkey combinations from the keyboard, or via a menu driven multilingual on-screen display (OSD) system.

Feature :

A single console controls up to 256 computers by cascade to 2 levels and connect up to 16 switches.
Integrated KVM console with 19″ LCD panel
Dual Interface – supports computers with PS/2 or USB keyboards and mice
Multiplatform support – Windows 2000/XP/Vista, Linux, Mac, and Sun
Supports USB keyboards for PC, Mac and Sun
Auto PS/2 and USB interface detection
USB or PS/2 keyboard and mouse emulation – computers boot even when the console focus is elsewhere
Superior video quality – up to 1280 x 1024 @ 75 Hz; DDC2B
Convenient computer switching via front panel push buttons, hotkeys, or multilingual on-screen display (OSD) menu
Two level password security – only authorized users view and control computers; up to four users and an administrator with a separate profi le for each
Auto Scan feature for monitoring user-selected computers
Broadcast mode – operations simultaneously performed on all selected computers
Hot pluggable – add or remove computers without having to power down the switch
Buzzer on/off via hotkey and OSD
Rack mountable
Keyboard Language support: English(US); English(UK); German;German(Swiss); French; Spanish; Traditional Chinese; Japanese; Korean;Swedish; Italian; Russian; Hungarian; Greek

Diagram :

Diagram CL1316

Specification :

Computer Connections	Direct		16
	Maximum		256 (via Cascade)
Port Selection			OSD, Hotkeys, Pushbuttons
Connectors	KVM Ports		16 x SPHD-17 Female (Yellow)
	FW Upgrade		1 x RJ-11 Female (Black)
	Power		1 x 3-prong AC Socket (IEC60320/C14)
Switches	Reset		1 x Semi-recessed Pushbutton
	Power		1x Rocker
	FW Upgrade		1 x Slide
	LCD Control		4 x Pushbutton
	LCD On/Off		1 x Pushbutton
	Port		16 x Pushbutton
LEDs	Online		16 (Orange)
	Selected		16 (Green)
	Power	KVM	1 (Dark Green)
		LCD	1 (Orange)
	Lock	Num	1 (Green)
		Caps	1 (Green)
		Scroll	1 (Green)
Emulation	Keyboard / Mouse		PS/2, USB
Video	19-Inch LCD		1280×1024 @ 75 Hz； DDC2B
Scan Interval			1-255 seconds
I/P Rating			100-240 VAC; 50/60 Hz; 1A
Power Consumption	19-Inch LCD		120V, 22 W / 230V, 22.9 W
Environment	Operating Temp.		0-50°C
	Storage Temp.		-20-60°C
	Humidity		0 – 80% RH, Non-condensing
Physical Properties	Housing		Metal + Plastic
	Weight		12.58 kg
	Dimensions ( L x W x H )		68.90 x 48.30 x 4.40 cm

The specification and pictures are subject to change without notice.
All trademarks and logos are the properties of their respective holders.

ATEN CL1308N 19” LCD KVM Switch

Posted on December 17, 2014 by

With limited server room space and rising maintenance costs, network administrators are now more than ever looking for solutions that reduce both costs and space requirements. ATEN LCD KVM Switches offer a space saving, streamlined approach to KVM switching technology by integrating an LCD panel, full keyboard, and touchpad into a 1U rack-mountable sliding housing. The CL1308 LCD KVM Switch features an integrated 19″ LCD panel allowing access and control with up to 8 computers from a single console (keyboard, mouse, and monitor). As many as 8 additional switches can be cascaded bringing the total number of connected computers to 128 computers that can be controlled from a single keyboard-monitor-mouse console.

CL1308-2 Setup is fast and easy; plugging cables into their appropriate ports is all that is needed. The switch supports both USB and PS/2 connections for the computers. The CL1308 intercepts keyboard input directly, thus eliminating the need for any software configuration. Switching between computers can be easily accomplished either by manually pressing the front panel push button port LEDs, entering hotkey combinations from the keyboard, or via a menu driven multilingual on-screen display (OSD) system.

Feature :

A single console controls up to 128 computers by cascade to 2 levels and connect up to 8 switches.
Integrated KVM console with 19″ LCD panel
Dual Interface – supports computers with PS/2 or USB keyboards and mice
Multiplatform support – Windows 2000/XP/Vista, Linux, Mac, and Sun
Supports USB keyboards for PC, Mac and Sun
Auto PS/2 and USB interface detection
USB or PS/2 keyboard and mouse emulation – computers boot even when the console focus is elsewhere
Superior video quality – up to 1280 x 1024 @ 75 Hz; DDC2B
Convenient computer switching via front panel push buttons, hotkeys, or multilingual on-screen display (OSD) menu
Two level password security – only authorized users view and control computers; up to four users and an administrator with a separate profi le for each
Auto Scan feature for monitoring user-selected computers
Broadcast mode – operations simultaneously performed on all selected computers
Hot pluggable – add or remove computers without having to power down the switch
Buzzer on/off via hotkey and OSD
Rack mountable
Keyboard Language support: English(US); English(UK); German;German(Swiss); French; Spanish; Traditional Chinese; Japanese; Korean;Swedish; Italian; Russian; Hungarian; Greek

Diagram :

Diagram CL1308

Specification :

Computer Connections	Direct		8
	Maximum		128 (via Cascade)
Port Selection			OSD, Hotkeys, Pushbuttons
Connectors	KVM Ports		8 x SPHD-17 Female (Yellow)
	FW Upgrade		1 x RJ-11 Female (Black)
	Power		1 x 3-prong AC Socket (IEC60320/C14)
Switches	Reset		1 x Semi-recessed Pushbutton
	Power		1x Rocker
	FW Upgrade		1 x Slide
	LCD Control		4 x Pushbutton
	LCD On/Off		1 x Pushbutton
	Port		8 x Pushbutton
LEDs	Online		8 (Orange)
	Selected		8 (Green)
	Power	KVM	1 (Dark Green)
		LCD	1 (Orange)
	Lock	Num	1 (Green)
		Caps	1 (Green)
		Scroll	1 (Green)
Emulation	Keyboard / Mouse		PS/2, USB
Video	19-Inch LCD		1280×1024 @ 75 Hz ; DDC2B
Scan Interval			1-255 seconds
I/P Rating			100-240 VAC; 50/60 Hz; 1A
Power Consumption	19-Inch LCD		120V, 22 W / 230V, 22.9 W
Environment	Operating Temp.		0-50°C
	Storage Temp.		-20-60°C
	Humidity		0 – 80% RH, Non-condensing
Physical Properties	Housing		Metal + Plastic
	Weight		12.42 kg
	Dimensions ( L x W x H )		68.90 x 48.30 x 4.40 cm

The specification and pictures are subject to change without notice.
All trademarks and logos are the properties of their respective holders.

ATEN CL5816N 16-Port Dual Rail 19in. LCD KVM

Posted on January 2, 2014 by

The CL5816N Slideaway™ Dual Rail LCD KVM Switch is a control unit that allows access to multiple computers from two PS/2 or USB KVM consoles. An extra console port is provided on the rear panel to manage the LCD KVM switch from an optional external consoles.The CL5816N 19″ LCD monitor and keyboard/touch pad modules slide independently of each other. To maximize space in your data center, the keyboard/touch pad module slides back to “hide away” when not in use, while the thin profile LCD monitor rotates back – flush against the rack – allowing convenient monitoring of computer activity. Quickly and conveniently switch computer access with station and port selection pushbutton switches located on the keyboard module. Even when the keyboard module is in the retracted position you can still switch access with the Port Up/Port Down pushbuttons located on the monitor module. The CL5808 supports both PS/2 and USB keyboards and mice for the connected computers, and the CL5816 supports USB peripheral devices to be used with the attached computers. A single CL5816N can control up to 16 computers. As many as 31 additional compatible KVM switches can be daisy chained together, so that up to 512 computers can all be controlled from a single keyboard, monitor, and mouse console

Feature :

Integrated KVM console with 19″ LCD in a Dual Rail housing
Space saving technology – up to two consoles (one bus) control up to 16 computers
Daisy-chain up to 31 additional units*– control up to 512 computers from two consoles (one bus)
Dual Interface – supports computers and console with PS/2 or USB keyboards and mice
Supports USB peripherals for computers connected to the local station
LCD module rotates up to 120 degrees for a more comfortable viewing angle
Console Lock – enables the console drawer to remain securely locked away in position when not in use
Multiplatform support – Windows, Linux, Mac, and Sun
Supports multimedia USB keyboards for PC, Mac and Sun
Auto PS/2 and USB interface detection
Keyboard and mouse emulation (PS/2 and USB) for smooth switching and simultaneous booting of multiple computers even when the console focus is elsewhere
Extra console port – manage computers in the LCD KVM switch from an external console (monitor, USB keyboard, and USB mouse)
*With compatible KVM Switches:ACS1208A, ACS1216A,CS1708A,CS1716A
Supports external USB mouse
Superior video quality – supports resolutions up to 1280 x 1024 @ 75 Hz
No software required – convenient computer selection via front panel pushbuttons, hotkeys, and multilingual on-screen display (OSD) menus
Auto-senses station’s position on daisy chained installations; no need for manual dip switch setting; front panel led indicates station’s position
Port names automatically reconfigured when station sequence is changed
Two level password security – only authorized users can view and control computers
LCD power button helps save energy and prolong display’s life
Supports one administrator and four user accounts with separate profiles
Auto Scan mode enables continuous monitoring of user-selected computers
Broadcast support – commands from the keyboard can be broadcast to all available computers on the installation
Hot pluggable – add or remove computers without having to power down the switch
Beeper on/off via hotkey and OSD

Firmware upgrades to all the chained KVM switches at the same time via the daisy chain cable

Rack Mounting Kit	Depth (cm)
2X-010G (Long/Optional)	70 – 105
Short (Standard)	52 – 85

Easy Installation Rack Mounting Kit	Depth (cm)
2X-012G (Long/Optional)	68 – 105
2X-011G (Short/Optional)	57 – 70

Diagram :

Specification :

Computer Connections
Direct	16
Daisy Chain or Cascading	512 [Daisy Chain]
Port Selection	OSD, Hotkeys, Pushbuttons
Console Connectors
Secondary Console	1x SPHD-18 Male (additional Console Port)
Flash ROM Upgrade	1x RJ-11 Female
Extra Mouse	1x RJ-11 Female
USB Peripheral	1x USB Type-A Female(USB Peripheral share)
CPU Connectors
Keyboard, Mouse, and Monitor	16 SPHD-15/17 [F]
Daisy Chain	1x DB-25 Male
Power Connections	1x 3-Prong AC Socket
Switches
Port Selection	16 x Pushbutton
LCD Adjustment	4 x Pushbutton
LCD Power	1x Pushbutton
F/W Upgrade	1x Slide
Power	1x Rocker Switch
Reset	1x Semi-recessed Pushbutton
LEDs
On Line	16 (Orange)
Selected	16 (Green)
Station ID	2x 7-segment LED Dispaly(Orange)
Power On	1 (Dark Green)
Emulation
Keyboard	USB, PS/2
Mouse	USB, PS/2
Video Performance
Local	19″ LCD – 1280×1024@75 Hz; DDC2B
Remote	1920×1440 (From Secondary Console)
Power Input Rating
Per AC Power Inlet, 50/60Hz	100~240V
Power Consumption	120V 31.6W 108 BTU / 240V 32.4W 110 BTU

Physical Properties
Unit Weight	34Lbs
Housing	Metal / Plastic
Case Weight	46.7 Lbs.
Case Dimension	32.5 x 26.4 x 5.6 in
Unit Dimension	26.8 x 18.9 x 1.74 in
Case Qty	1 ea

The specification and pictures are subject to change without notice.
All trademarks and logos are the properties of their respective holders.

ATEN CL5808N 8-Port 19in. Dual Rail LCD Console

Posted on December 30, 2013 by

The CL5808 Slideaway™ Dual Rail LCD KVM Switch is a control unit that allows access to multiple computers from two PS/2 or USB KVM consoles. An extra console port is provided on the rear panel to manage the LCD KVM switch from an optional external consoles.

The CL5808 19″ LCD monitor and keyboard/touch pad modules slide independently of each other. To maximize space in your data center, the keyboard/touch pad module slides back to “hide away” when not in use, while the thin profile LCD monitor rotates back – flush against the rack – allowing convenient monitoring of computer activity. Quickly and conveniently switch computer access with station and port selection pushbutton switches located on the keyboard module. Even when the keyboard module is in the retracted position you can still switch access with the Port Up/Port Down pushbuttons located on the monitor module. The CL5808 supports both PS/2 and USB keyboards and mice for the connected computers, and the CL5808 supports USB peripheral devices to be used with the attached computers. A single CL5808 can control up to 8 computers. As many as 31 additional compatible KVM switches can be daisy chained together, so that up to 256 computers can all be controlled from a single keyboard, monitor, and mouse console.

Feature :

Integrated KVM console with 19″ LCD in a Dual Rail housing
Space saving technology – up to two consoles (one bus) control up to 8 computers
Daisy-chain up to 31 additional units*– control up to 256 computers from two consoles (one bus)
Dual Interface – supports computers and console with PS/2 or USB keyboards and mice
Supports USB peripherals for computers connected to the local station
LCD module rotates up to 120 degrees for a more comfortable viewing angle
Console Lock – enables the console drawer to remain securely locked away in position when not in use
Multiplatform support – Windows, Linux, Mac, and Sun
Supports multimedia USB keyboards for PC, Mac and Sun
Auto PS/2 and USB interface detection
Keyboard and mouse emulation (PS/2 and USB) for smooth switching and simultaneous booting of multiple computers even when the console focus is elsewhere
Extra console port – manage computers in the LCD KVM switch from an external console (monitor, USB keyboard, and USB mouse)
*With compatible KVM Switches:ACS1208A, ACS1216A,CS1708A,CS1716A
Supports external USB mouse
Superior video quality – supports resolutions up to 1280 x 1024 @ 75 Hz
No software required – convenient computer selection via front panel pushbuttons, hotkeys, and multilingual on-screen display (OSD) menus
Auto-senses station’s position on daisy chained installations; no need for manual dip switch setting; front panel led indicates station’s position
Port names automatically reconfigured when station sequence is changed
Two level password security – only authorized users can view and control computers
LCD power button helps save energy and prolong display’s life
Supports one administrator and four user accounts with separate profiles
Auto Scan mode enables continuous monitoring of user-selected computers
Broadcast support – commands from the keyboard can be broadcast to all available computers on the installation
Hot pluggable – add or remove computers without having to power down the switch
Beeper on/off via hotkey and OSD

Firmware upgrades to all the chained KVM switches at the same time via the daisy chain cable

Rack Mounting Kit	Depth (cm)
2X-010G (Long/Optional)	70 – 105
Short (Standard)	52 – 85

Easy Installation Rack Mounting Kit	Depth (cm)
2X-012G (Long/Optional)	68 – 105
2X-011G (Short/Optional)	57 – 70

Diagram :

Specification :

Computer Connections
Direct	8
Daisy Chain or Cascading	256 (Daisy-Chain)
Port Selection	OSD, Hotkeys, Pushbuttons
Console Connectors
Secondary Console	1x SPHD-18 Male (additional Console Port)
Flash ROM Upgrade	1x RJ-11 Female
Extra Mouse	1x USB Type-A Female(additional Mouse port)
USB Peripheral	1x USB Type-A Female(USB Peripheral share)
CPU Connectors
Keyboard, Mouse, and Monitor	8x SPHD-15/17 Female
Daisy Chain	1x DB-25 Male
Power Connections	1x 3-Prong AC Socket
Switches
Port Selection	8x Pushbutton
LCD Adjustment	4 x Pushbutton
LCD Power	1x Pushbutton
F/W Upgrade	1x Slide
Power	1x Rocker Switch
Reset	1x Semi-recessed Pushbutton
LEDs
On Line	8(Orange)
Selected	8(Green)
Station ID	2x 7-segment LED Dispaly(Orange)
Power On	1 (Dark Green)
Emulation
Keyboard	USB, PS/2
Mouse	USB, PS/2
Video Performance
Local	19″ LCD – 1280×1024@75 Hz; DDC2B
Remote	1920×1440 (From Secondary Console)
Scan Interval	1-255 sec.
Power Input Rating
Per AC Power Inlet, 50/60Hz	100~240V
Power Consumption	120V, 30.1W,103 BTU ; 230V, 30.7W, 105 BTU
Housing
Case	Metal / Plastic
Environment
Humidity	0-80% RH, Non-condensing
Operation Temperature	32~122 F (0~50 C)
Storage Temperature	-4~140 F(-20~60 C)

Physical Properties
Unit Weight	33 Lbs
Case Qty	1 ea
Case Weight	45.6 Lbs.
Unit Dimension	26.8 x 18.9 x 1.74 in
Case Dimension	32.5 x 26.4 x 5.6 in

The specification and pictures are subject to change without notice.
All trademarks and logos are the properties of their respective holders.
