MOXA MiiNePort E1-ST

10/100 Mbps embedded serial device servers

Moxa’s MiiNePort E1 embedded device servers are designed for manufacturers who want to add sophisticated network connectivity to their serial devices with minimal integration effort. The MiiNePort E1 is empowered by the MiiNe, Moxa’s second generation SoC, which supports 10/100 Mbps Ethernet, up to 921.6 Kbps serial baudrate, a versatile selection of ready-to-use operation modes, and requires only a small amount of power. By using Moxa’s innovative NetEZ technology, the MiiNePort E1 can be used to convert any device with a standard serial interface to an Ethernet enabled device in no time. In addition, the MiiNePort E1 is the size of an RJ45 connector, making it easy to fit into virtually any existing serial device.

The MiiNe—Moxa’s 2nd Generation SoC

The MiiNe was created to provide manufacturers with a competitive embedded serial-to-Ethernet solution. The MiiNePort E1, which uses the MiiNe for its SoC, is one of the world’s tiniest embedded device servers, and has the lowest power consumption of any similar product. The MiiNe has the following features:
1. Designed for 1 or 2-port serial-to-Ethernet applications
2. Uses a 32-bit ARM 7 core
3. Uses Moxa’s own advanced UART technology
4. Has 2 MB Flash and 4 MB SDRAM memory built in

NetEZ Technology

Moxa’s NetEZ technology gives serial device manufacturers a range of powerful tools for integrating Ethernet capability into serial devices:

EXTrigger : Want to troubleshoot your network with ease? Use the MiiNePort’s EXTrigger button to reset network settings with just one push.

SCM : Need an easy tool to configure the network through serial communication inside the device? Try MiiNePort’s friendly SCM (Serial Command Mode).

AutoCFG : Tired of spending a large amount of time and effort setting up a network? Not anymore! The MiiNePort’s AutoCFG makes auto-configuration during manufacturing possible.

MCSC : Ever wanted your device to be a server and client at the same time? The MiiNePort’s MCSC (Multi-channel Serial Communication) provides dual connections and dual channels for multi-task applications!.

Moxa’s NetEZ technology makes the MiiNePort E1 the world’s most user-friendly embedded device server by promising ease-of-use with minimal integration work required.

Feature :

Features and Benefits

• Same size as an RJ45 connector—only 33.9 x 16.25 x 13.5 mm
• Extremely low power consumption—only 160 mA @ 3.3 VDC input
• Uses the MiiNe, Moxa’s second generation SoC
• NetEZ technology makes integration incredibly easy
• Versatile choice of operation modes: Real COM, RFC2217, TCP, and UDP

Diagram :

Specification :

• Form Factor Type	Drop-in module
Dimensions	33.9 x 16.25 x 13.5 mm (1.33 x 0.64 x 0.53 in)
Weight	9 g
• System Information
CPU	32-bit ARM Core
RAM	4 MB built in
Flash	2 MB built in
• Ethernet Interface
Number of Ports	1
Speed	10/100 Mbps, auto MDI/MDIX
Connector	RJ45 (with magnetics)
Magnetic Isolation Protection	1.5 KV built-in
LEDs	10BASE-T & 100BASE-TX Link Activity, Fault/In-Use
• Serial Interface
Number of Ports	1
Transmission Format	Standard TTL
• Serial Communication Parameters
Data Bits	5, 6, 7, 8
Stop Bits	1, 1.5, 2
Parity	None, Even, Odd, Space, Mark
Flow Control	RTS/CTS, DTR/DSR, XON/XOFF
Baudrate (non-standard baudrates supported)	MiiNePort E1: 50 bps to 230.4 Kbps MiiNePort E1-H: 50 bps to 921.6 Kbps
• Serial Signals
TTL	TxD, RxD, RTS, CTS, RST (reset circuit), GND
• Digital I/O Pins
GPIO	3 configurable I/O pins (1 DO, 1 DI, 1 DI/O)
• Software
Network Protocols	ICMP, ARP, IP, TCP, UDP, DHCP, HTTP, SNMP V1, SMTP, TFTP, Auto IP, Telnet, BOOTP
Configuration Options	Web Console, Serial Console (Serial Command Mode), Telnet Console, Windows Utility
Windows RealCOM Drivers	Windows 95/98/ME/NT/2000, Windows XP/2003/Vista/2008/7 x86/x64, Embedded CE 5.0/6.0, XP Embedded
Fixed TTY Drivers	SCO Unix, SCO OpenServer, UnixWare 7, SVR 4.2, QNX 4.25, QNX 6, Solaris 10, FreeBSD, AIX 5.x
Linux Real TTY Drivers	Linux kernel 2.4.x, 2.6.x, 3.x
Operation Modes	TCP Server, TCP Client, TCP Mixed, UDP, RealCOM, RFC 2217, MCSC
• Environmental Limits
Operating Temperature	Standard Models: 0 to 55°C (32 to 131°F) Wide Temp. Models: -40 to 85°C (-40 to 185°F)
Storage Temperature (package included)	-40 to 60°C (-40 to 140°F)
Ambient Relative Humidity	5 to 95% (non-condensing)
• Power Requirements
Input Voltage	3.3 VDC (±5%)
Power Consumption	• MiiNePort E1: 160 mA @ 3.3 VDC max. • MiiNePort E1-H: 195 mA @ 3.3 VDC max.
• Standards and Certifications
EMC	• Radiated & conducted emmisions: Complies with Class B limits of EN 55022:1998 • Direct & Indirect ESD: Complies with EN 55024:1998 • Electrical Fast Transient/Burst Immunity: Complies with EN 55024:1998 • Power Frequency Magnetic Field Immunity: Co
Shock	500 g’s for non-operational shock
Vibration	20 g’s for non-operational vibration
• Reliability
Automatic Reboot Trigger	Built-in WDT (watchdog timer)
MTBF (mean time between failures)	5,515,294 hrs
• Warranty
Warranty Period	5 years
Details	See www.moxa.com/warranty
